DYNAQUIP CONTROLS PHH23ATDA032A Automated Ball Valve, 2 Pcs, Full Port, Double Acting Actuator, Viton Seat Material
Item: AE8FKTModel: PHH23ATDA032ACross Ref: 6CX04
7 In Stock
Ships within 2 days via
13.00% off
€649.88 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Ball Valve |
| 3-a Certified | Not Rated |
| Actuation | Pneumatically Actuated |
| Actuator Air Port Connection Size | 1/8" |
| Actuator Air Port Connection Type | NPT |
| Actuator Air Pressure Range | 95 psi to 315 psi |
| Actuator Features | Position Indicator |
| Actuator Operation | Air To Air |
| Actuator Series | HP |
| Actuator Type | Double Acting |
| Ambient Temp. | -4°F to +176°F |
| Ansi Flange Class | Not Applicable |
| Average Surface Roughness (ra) | Not Applicable |
| Ball Finish | Brass , Chrome Plated |
| Ball Port Style | Full Port |
| Ball Valve Product Group | Actuated |
| Body Material | Brass |
| Body Material (hydraulic Valves) | Brass |
| Body Style | Inline |
| Coefficient Of Volume | 19 |
| Connection Gender | Threaded |
| Connection Gender Side 2 | Female |
| Connection Gender-side 1 | Female |
| Connection Size-side 1 | 1/2" |
| Connection Size-side 2 | 1/2" |
| Connection Type | FNPT x FNPT |
| Connection Type-side 1 | NPT |
| Connection Type-side 2 | NPT |
| Control Type | Pneumatically Operated - Double Acting |
| Cwp | 600 psi |
| Fail Safe Position | Fail Last |
| Flow Direction | 2-Way |
| For Media | Air, Oil, Water |
| General Connection Type | Female NPT |
| Handle Style | Pneumatically Operated |
| Included Mounting | Actuator Mounting Pad |
| Included Pilot Solenoid | 115V AC Pilot Solenoid |
| Ip Rating | IP65 |
| Max. Actuator Air Pressure | 315 psi |
| Max. Actuator Ambient Temp. | 176°F |
| Max. Differential Pressure | 300 psi |
| Max. Inlet Pressure | 120 psi |
| Max. Media Temp. | 370°F |
| Max. Operating Temp. | 370°F |
| Max. Pressure | 600 psi |
| Max. Pressure (cwp) | 600 psi |
| Max. Pressure-combustible Gas | Not Rated |
| Max. Pressure-steam | 150 psi |
| Media Temp. | -20°F to +370°F |
| Min. Actuator Air Pressure | 95 psi |
| Min. Actuator Ambient Temp. | -4°F |
| Min. Media Temp. | -20°F |
| Mount | Direct |
| Mounting Type | Inline Threaded |
| Nema Enclosure Rating | NEMA 4, NEMA 4X |
| No. Of Pieces | 2 |
| Nominal Valve Size | 1/2" |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Operation | Double Acting |
| Overall Length | 2.6" |
| Pilot Solenoid Voltage | 115V AC |
| Pipe Schedule Compatibility | Not Applicable |
| Pipe Size | 1/2" |
| Port | Full |
| Porting Style | Full Port |
| Required Pressure | 80 psi |
| Seal Material | FKM |
| Seal Type | Viton |
| Seat Material | FKM |
| Stem Finish | Brass , Nickel Plated |
| Temp. | +14°F to +140°F |
| Type | Full Port |
| Vacuum Service Rating | 29 in. hg |
| Valve Body Style | Straight |
| Valve Construction | Two-Piece |
| Valve Deactivated State | normally Open (NO), normally Closed (NC) |
| Valve Series | PHH Series |
| Valve Ways | 2-Way |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 1.35 |
| Ship height (cm) | 10.16 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 14.73 |
| HS code | 8481809040 |
| Country of Origin | CN |
Product Variants
| Model | Nominal Valve Size | Connection Size-side 2 | Connection Size-side 1 | Ball Finish | Stem Finish | Operation | Actuator Operation | Actuator Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| PHH24ATDA032A | 3/4" | 3/4" | 3/4" | Chrome Plated | Nickel Plated | Double Acting | Air To Air | Double Acting | €754.45 | |
| PHH25ATDA052A | 1" | 1" | 1" | Chrome Plated | Nickel Plated | Double Acting | Air To Air | Double Acting | €846.85 | |
| PHH26ATDA052A | 1 1/4" | 1 1/4" | 1 1/4" | Chrome Plated | Nickel Plated | Double Acting | Air To Air | Double Acting | €966.42 | |
| PHH27ATDA063A | 1 1/2" | 1 1/2" | 1 1/2" | Chrome Plated | Nickel Plated | Double Acting | Air To Air | Double Acting | €1,128.41 | |
| PHH28ATDA063A | 2" | 2" | 2" | Chrome Plated | Nickel Plated | Double Acting | Air To Air | Double Acting | €1,288.98 | |
| PHH23ATSR05210A | 1/2" | 1/2" | 1/2" | Chrome Plated | Nickel Plated | Spring Return | Air To Spring | Single Acting Spring Return | €802.69 | |
| PHH24ATSR05212A | 3/4" | 3/4" | 3/4" | Chrome Plated | Nickel Plated | Spring Return | Air To Spring | Single Acting Spring Return | €904.58 |
