DESTACO RPW-500-1-NS-V 2-Jaw Pneumatic Parallel Gripper, 2.614 Inch Size, 1.25 Inch Cylinder Bore, 40-100 Psi
Item: EC9HACModel: RPW-500-1-NS-V
In Stock
Get it by Monday, Aug 31
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Gripper |
| Accessories | OISP-014, OISN-014, CABL-010, CABL-013, OFSV-002, OFSV-005 |
| Cylinder Bore | 1 1/4" |
| Grip Force | 150 lbf. |
| Handle Color | Red |
| Jaw Operation | Non-Synchronous Available |
| Length | 2.614" |
| Max. Finger Length | 12" |
| Pressure | 40 psi to 100 psi |
| Repeatability | -0.001" to +0.001" |
| Spindle Included | No |
| Standard Temp. Range | -30°F to +180°F |
| Stroke | 1 1/2" |
| Viton Temp. Range | -20°F to +300°F |
Shipping Info:
| Ship weight (kg) | 1.35 |
| Ship length (cm) | 6.64 |
Product Variants
| Model | Max. Finger Length | Stroke | Grip Force | Cylinder Bore | Overall Height | Pressure | Min. Operating Pressure | Stroke Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| RPW-500-2 | - | - | - | - | 2 5/8" | - | 40 psi | 2 1/2" | €3,818.23 | |
| RPW-250M-NS | 4" | 3/4" | 50 lbf. | 0.63" | - | 40 psi to 100 psi | - | - | - | RFQ
|
| RPW-250M-V | 4" | 3/4" | 50 lbf. | 0.63" | - | 40 psi to 100 psi | - | - | - | RFQ
|
| RPW-250-NS | 4" | 3/4" | 50 lbf. | 0.63" | - | 40 psi to 100 psi | - | - | - | RFQ
|
| RPW-250-NS-V | 4" | 3/4" | 50 lbf. | 0.63" | - | 40 psi to 100 psi | - | - | - | RFQ
|
| RPW-250-V | 4" | 3/4" | 50 lbf. | 0.63" | - | 40 psi to 100 psi | - | - | - | RFQ
|
| RPW-375-1-NS-V | 6" | 1" | 90 lbf. | 0.87" | - | 40 psi to 100 psi | - | - | - | RFQ
|
