DESTACO 9530-2R Pneumatic Swing Clamp, Aluminium, 90 lb Holding Capacity

Destaco 9530-2R pneumatic swing clamp employs a strong hydraulic clamp mechanism that is intended to provide quick clamping in secondary manufacturing operations on both non metallic and metallic products, for increased productivity. It features a compact design that makes it adaptable for tight spaces and is equipped with an arm that rotates at the top of the stroke. The clamp offers lock angle repeatability with high accuracy, thereby making clamping on an extremely compact area easily possible. The clamp is used where uninterrupted & rapid access to the clamping station is needed, and is ideal for fixturing, testing, assembling and welding applications in the automotive and food & packaging industries. This double acting, non locking clamp delivers clamping force in direct proportion to inlet pressure and bore size, and has a shielded piston rod for protection from weld spatter. This clamp offers field adjustable swing direction from left to right at 90 degrees and is sensor ready for T slot or round style sensors. This pneumatic clamp has a block style body for ease-of-installation and comes with rod weld covers to protect the rod throughout the stroke. It is capable of accommodating 6.5 mm x 5 mm T slots and 4 mm round style switches, as well as offering field adjustable swing direction (left / right). Additionally, this clamp has been tested for several million cycles and features a robust design to improve the fundamental functions of the clamp and for delivering consistency. Destaco 9530-2R pneumatic swing clamp can work under pressure ranging between 45 psig and 120 psig, at temperatures up to 140 degrees Fahrenheit. The clamp arm ensures maximum, fatigue less clamping force (maximum total stroke of 20 mm) and is equipped with a pneumatic cylinder having an input port to connect to a source of compressed air. It is compatible with multiple mounting accessories including body mount flanges & replacement seal kits for unobstructed functioning of the clamps.

Uses:

This Destaco 9530-2R pneumatic swing clamp offers a broad combination of features, making it adaptable to applications such as fixturing, testing, assembling and welding applications in the automotive and food & packaging industries.

Features:

• Destaco 9530-2R pneumatic swing clamp is suitable for tight spaces, owing to arm motion that rotates at the top of strokes.
• It features aluminium construction for corrosion resistance in harsh welding environments.
• The clamp comes with a rod weld cover for protection of rod throughout the stroke and from weld spatter.
• It can be mounted on any face and an optional side flange mounting kit is also available for easy mounting.
• This clamp is switch ready for sensors to ensure low profile mounting.
• The unique design of 9530-2R pneumatic swing clamp allows the attached arm to swing 90 degrees on the horizontal plane, before being clamped.
• This clamp arm guarantees fatigue less clamping force with a maximum total stroke of 20 mm.
• This pneumatic swing clamp can work under pressures ranging between 45 psig and 120 psig, at temperatures up to 140 degrees Fahrenheit.

Compatible Accessories:

• Destaco 953092: These replacement seal kits are designed for the unobstructed functioning of the brand's 9530-2R pneumatic swing clamp.

Standards and Approvals:

This Destaco 9530-2R pneumatic swing clamp is ISO 9001:2015 and ISO 14001:2015 certified.

Installation:

• This Destaco 9530-2R pneumatic swing clamp features a block style body with side flange to allow the attachment of multiple mounting accessories. It is equipped with a clamp arm featuring tapped holes to accommodate spindle accessories, thereby enabling easy surface mounting.

Frequently Asked Questions:

Q. What is a pneumatic swing clamp?

A. Destaco swing clamps or pneumatic swing clamps are non-locking clamps that deliver clamping force directly proportional to inlet pressure and bore size. They are ideal for applications that require only low clamping force, and keep the clamping area free of straps & clamping components, for unrestricted workpiece loading and unloading.

Q. Are Destaco 9500 Series pneumatic swing clamps available in different cylinder bore sizes?

A. Yes, Destaco 9500 Series pneumatic swing clamps are available in cylinder bore sizes of 22 mm, 32 mm, 40 mm and 50 mm.

Q. How to choose between a left hand and a right hand swing clamp?

A. To determine whether a left or right swing variant is ideal, you need to visualise the arm from above during the clamping stroke. Arms moving clockwise are right hand swing arms and arms moving counter clockwise are left hand swing arms.

Q. What accessories do Destaco pneumatic swing clamps require to function?
