DAYTON 4GU70 Electric Chain Hoist 300 Lb. 10 Feet
Get it by Thursday, Dec 25
10.00% off
€1,626.69 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Electric Chain Hoist |
| Amperage Draw | 3A |
| Amps @ Low Volts | 3A |
| Body Depth | 4 5/8" |
| Body Finish | Powder Coated |
| Body Length | 14 1/4" |
| Body Material | Steel |
| Body Width | 6" |
| Brake Type | Electric Disc |
| Capacity | 300 lbs. |
| Chain Finish | Powder Coated |
| Chain Grade | Grade 80 |
| Chain Material | Alloy Steel |
| Classification | H2 |
| Clutch | Overload Limiting |
| Clutch Type | Overload Limiting |
| Color | Red |
| Configuration | Hook Mounted - No Trolley |
| Control | Push Button Pendant |
| Control Cord | 6 ft. |
| Controller Cord Length | 10 ft. |
| Duty Classification | H2 - Light Duty |
| Features | Not Applicable |
| Finish | Powder Coated |
| Fixed Lift Speed | 14 FPM |
| For Max. Beam Flange Height | Not Applicable |
| For Max. Beam Height | Not Applicable |
| For Maximum Beam Flange Width | Not Applicable |
| For Min. Beam Flange Height | Not Applicable |
| For Minimum Beam Flange Width | Not Applicable |
| For Minimum Beam Height | Not Applicable |
| For Outdoor Use | No |
| Headroom | 14 1/2" |
| Headroom Size | 14 1/2" |
| Housing Depth | 4 5/8" |
| Housing Length | 14 1/4" |
| Housing Width | 6" |
| Includes Brake | Brake Included |
| Includes Clutch | Clutch Included |
| Ip Rating | Not Applicable |
| Lift | 10 ft. |
| Lift Speed | 14 FPM |
| Lifting Capacity | 300 lbs. |
| Lifting Hook Material | Steel |
| Lifting Hook Opening Width | 14 1/2" |
| Lifting Hook Type | Hook With Safety Latch |
| Load Capacity | 300 lbs. |
| Lubrication | Grease |
| Manufacturers Warranty Length | 1 yr. |
| Material | Aluminum |
| Max Current Draw | 3A |
| Maximum Lift Speed | Not Applicable |
| Maximum Lifting Length | 10 ft. |
| Min. Between Hooks | 14 1/2" |
| Min. Radius Curve | Not Applicable |
| Minimum Lift Speed | Not Applicable |
| Minimum Retracted Length | 14 1/2" |
| Motor Hp | 1/8 hp |
| Mount Type | Hook Mounted - No Trolley |
| Number Of Load Chains | 1 |
| Number Of Reeves | 1 |
| Number Of Speeds | 1 |
| Operating Voltage | 115V AC |
| Overload Protection Included | Yes |
| Pendant Ip Rating | IP54 |
| Phase | 1 |
| Reeving | 1 |
| Resistance Properties | Not Applicable |
| Starts And Stops Per Hour | 75 |
| Thermal Protection | Included |
| Tonnage - Lifting Capacity | 0.125 ton. |
| Trolley Wheel Dia. | Not Applicable |
| Trolley Wheel Material | Not Applicable |
Shipping Info:
| Ship weight (kg) | 12.13 |
| Ship height (cm) | 33.27 |
| Ship length (cm) | 44.96 |
| Ship width (cm) | 26.67 |
| HS code | 8425110000 |
| Country of Origin | CN |
Product Variants
| Product | Model | Duty Classification | Lifting Capacity | Motor Hp | Lift Speed | Lifting Hook Opening Width | Max Current Draw | Number Of Reeves | Minimum Retracted Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
2GXG9 | H3 - Standard Duty | 1000 lbs. | 5/8 hp | 16 FPM | 19 3/32" | 10A | 1 | 19 3/32" | €4,058.91 | |
 |
2GXH3 | H3 - Standard Duty | 2000 lbs. | 1 hp | 16 FPM | 22 1/16" | 15A | 1 | 22 1/16" | €4,923.49 | |
 |
2GXH6 | H3 - Standard Duty | 4000 lbs. | 1 hp | 8 FPM | 26 25/32" | 15A | 2 | 26 25/32" | €5,929.00 | |
|
2XY32 | H2 - Light Duty | 1000 lbs. | 5/8 hp | 16 FPM | 19 3/32" | 10A | 1 | 19 3/32" | €4,272.94 | |
 |
2XY33 | H2 - Light Duty | 2000 lbs. | 5/8 hp | 8 FPM | 22 7/16" | 10A | 1 | 22 7/16" | €4,974.06 | |
 |
4GU71 | H2 - Light Duty | 500 lbs. | 1/8 hp | 7 FPM | 16" | 3A | 1 | 16" | €2,580.41 | |
 |
4ZY98 | H2 - Light Duty | 800 lbs. | 1/4 hp | 7 FPM | 16 3/4" | 3A | 1 | 16 3/4" | €1,979.22 |
