CLE-LINE C20748 Silver/deming Drill 3/4 High Speed Steel 118 Deg
Item: AE7DPFModel: C20748Cross Ref: 5X992
7 In Stock
Ships within 2 days via
10.00% off
€44.78 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Reduced Shank Drill Bit |
| Application | For Alloy And Carbon Steel, Cast Iron And Wood |
| Coolant Fed | Non-Coolant Through |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.75 |
| Depthdia. Ratio | 4Xd |
| Dimension Type | Fractional Inch |
| Drill Bit Dimension Type | Fractional Inch |
| Drill Bit Finish | Black Oxide |
| Drill Bit Grouping | Drill Bit |
| Drill Bit Material | High Speed Steel |
| Drill Bit Point Angle | 118° |
| Drill Bit Point Type | Conventional Point |
| Drill Bit Size | 3/4" |
| Drill Dia. | 3/4" |
| Drill Diameter | 3/4" |
| Drill Diameter Tolerance | -0.0012" to 0" |
| Drill Point | 118° |
| Finish | Black Oxide |
| Finish - Machining | Black Oxide |
| Flute Length | 3 1/8" |
| Flute Type | Spiral |
| Grade | General Purpose |
| Helix Angle | 28° |
| List Number | 1813 |
| Material | High Speed Steel |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | General Purpose |
| Max. Drilling Depth | 3" |
| No. Of Pieces | 1 |
| Number Of Flutes | 2 |
| Overall Length | 6" |
| Point Type | Conventional Point |
| Primary Material Application | Cast Iron, Steel |
| Primary Material Application Iso Code | K, P |
| Products By Industry | Fabricated Metals |
| Shank Dia. | 1/2" |
| Shank Length | 2 1/4" |
| Shank Type | Round |
| Shank Type - Machining | Straight |
| Silver & Deming Drill | No |
| Spiral Direction | Right Hand |
| Standards | Not Rated |
| System Of Measurement | Fractional Inch |
Shipping Info:
| Ship weight (kg) | 0.2 |
| Ship height (cm) | 15.49 |
| Ship length (cm) | 2.29 |
| Ship width (cm) | 2.29 |
| HS code | 8207502055 |
| Country of Origin | US |
Product Details:
- Flute Design (Standard)
Product Variants
| Model | Decimal Equivalent | Drill Bit Size | Silver & Deming Drill | Drill Diameter Tolerance | Drill Dia. | Max. Drilling Depth | Shank Dia. | Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| C20755 | 0.9375 | 15/16" | Yes | -0.0012" to 0" | - | 3 3/4" | 1/2" | High Speed Steel | €79.67 | |
| C20733 | 0.5156 | 33/64" | Yes | -0.0012" to 0" | 0.516" | 2 1/2" | 1/2" | High Speed Steel | €33.19 | |
| C20735 | 0.5469 | 35/64" | Yes | -0.0012" to 0" | 0.547" | - | 1/2" | High Speed Steel | €38.32 | |
| C20737 | 0.5781 | 37/64" | Yes | -0.0012" to 0" | 0.578" | 2 5/16" | 1/2" | High Speed Steel | €36.11 | |
| C20739 | 0.6094 | 39/64" | Yes | -0.0012" to 0" | 0.609" | 2 7/16" | 1/2" | High Speed Steel | €42.70 | |
| C20741 | 0.6406 | 41/64" | Yes | -0.0012" to 0" | 0.641" | 2 1/2" | 1/2" | High Speed Steel | €45.64 | |
| C20743 | 0.6719 | 43/64" | Yes | -0.0012" to 0" | 0.672" | 2 1/2" | 1/2" | High Speed Steel | €49.23 |
