BROWNING VTWE-231 767910 Mounted Cast Iron Wide Slot Take Up Ball Bearing
Get it by Monday, Aug 17
€211.82 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Ball Bearing |
| Bearing Insert Coating | Black Oxide Coated Inner Ring |
| Bearing Material | Steel |
| Bearing Type | Take Up |
| Bore Dia. | 25 mm |
| Bore Shape | Straight |
| Bore Size - Inch | 1.938" |
| Centerline To Front Face | 1 1/2" |
| Collar Outside Dia. | 2 3/4" |
| Compatible Frame Number | 3SF23, 6SF23, 9SF23, 12SF23 |
| Dynamic Radial Load Capacity | 7889 lbs. |
| Expansion | No |
| Expansion Type | Non-Expansion |
| Family Series | Browning Bearings |
| Height | 4 1/2" |
| Housing Bolt Through Hole | 1 1/8" |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Width | 2 1/8" |
| Insert Material | 52100 Bearing Steel, Black Oxided Inner |
| Insert Material | Bearing Steel, Black Oxided Inner |
| Inside Dia. | 1 15/16" |
| Length | 5 29/32" |
| Load Capacity | 7889 Lbs. Dynamic, 5216 Lbs. Static |
| Locking Device | Eccentric |
| Max. Operating Temp. | 200°F |
| Max. Speed | 3000 RPM |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Length | 5.9063" |
| Product Datasheet | browning-vfbs-212-cty.pdf |
| Retainer Type | Ball Riding Retainer |
| Seal Type | Single Lip Contact With Flinger |
| Series | VTWE Series |
| Shaft Dia. | 1 15/16" |
| Slot Spacing | 4 |
| Slot Width | 11/16" |
| Suitable For Use With | 18SF31, 3SF31, 6SF31, 9SF31, 12SF31 Frames |
| Type Of Bearing | Ball Bearing |
| Width | 2 1/8" |
Shipping Info:
| Ship weight (kg) | 2.39 |
| Ship height (cm) | 8.38 |
| Ship length (cm) | 17.53 |
| Country of Origin | MX |
