BROWNING 1061787 5R5V90 V-Belt Sheave, Multiple, Bushed Bore, 5 Groove, Cast Iron, 9 in OD, 1.13 to 3.75 in Bore Dia, R1 Bushing Type, Type 15 Web
Get it by Monday, Aug 17
€623.37 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | V-Belt Sheave |
| Belt Series | 5V Series |
| Bore Dia. | 1.13" to 3.75" |
| Bore Type | Split Taper |
| Bushing Bore Range | 1 1/8" to 3 3/4" |
| Bushing Type | R1 |
| Face Width | 3 3/4" |
| Keyway | Yes |
| Material | Cast Iron |
| Min. Plain Bore | No |
| No. Of Grooves | 5 |
| Outside Dia. | 9" |
| Overall Length | 3 11/16" |
| Pitch Dia. | 8.9" |
| Product Datasheet | browning-1097849.pdf |
| Suitable For Use With | Gripbelt 5V Cross Section V-Belt |
| System Of Measurement | Imperial |
| Type | Type 15 Web |
Shipping Info:
| Ship weight (kg) | 12.92 |
| Ship height (cm) | 22.86 |
| Ship length (cm) | 9.37 |
| Ship width (cm) | 22.86 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Pitch Dia. | Face Width | Bore Dia. | Type | Belt Series | Max. Pitch Dia. | Min. Pitch Dia. | Bushing Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1061852 | 9.15" | 3 3/4" | 1.13" to 3.75" | Type 15 Web | 5V Series | - | - | R1 | €694.12 | |
 |
1061928 | 9.65" | 3 3/4" | 1.13" to 3.75" | Type 15 Web | - | - | - | R1 | €802.75 | |
 |
1062132 | 11.7" | 3 3/4" | 1.13" to 3.75" | Type 15 Web | 5V Series | - | - | - | €878.85 | |
 |
1062496 | 15.9" | 3 3/4" | 1.13" to 3.75" | Type 15 Arm | - | - | - | R1 | €1,654.73 | |
 |
1061993 | 10 1/5" | 3 3/4" | 1.13" to 3.75" | Type 15 Web | 5V Series | 10 1/5" | 10 1/5" | R1 | €647.00 | |
 |
1060920 | 13.95" | 2 5/16" | 3/4" to 2 11/16" | Type 13 Arm | 3V Series | - | - | Q1 | €961.03 | |
 |
1060425 | 5.55" | 2 5/16" | 1/2" to 1 3/4" | Type 13 Web | 3V Series | - | - | P1 | €751.98 |
