BRAD HARRISON 116020A01F060 Extension Cordset, 7/8 To 16 Inch Thread, Male Straight x 7/8 To 16 Inch Thread, Female Straight, 6 Pin, Yellow, PVC
Item: CP2AUNModel: 116020A01F060Cross Ref: 2ENR9
7 In Stock
Ships within 2 days via
€132.72 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Extension Cordset |
| Amps | 8A |
| Cable Jacket Color | Yellow |
| Cable Jacket Material | PVC |
| Cable Length | 6 ft. |
| Color | Yellow |
| Connector Body Material | PVC |
| Connector Type | Female Straight To Male Straight |
| Cordset Type | Double-Ended |
| Coupling Style | Threaded |
| End 1 Connection | 7/8" Male |
| End 1 Gender | Male |
| End 1 Gender And Plug End | Female Straight |
| End 1 Keyway | Single |
| End 1 Mounting Orientation | Straight |
| End 1 No. Of Pins | 6 |
| End 1 Thread | 7/8"-16 |
| End 2 Connection | 7/8" Female |
| End 2 Connection Type | 7/8" |
| End 2 Gender | Female |
| End 2 Gender And Plug End | Male Straight |
| End 2 Keyway | Single |
| End 2 Mounting Orientation | Straight |
| End 2 No. Of Pins | 6 |
| End 2 Thread | 7/8"-16 |
| End Connection Type 1 | 7/8" |
| Family Series | Brad Harrison Cordsets |
| Features | Patented Quad Beam(TM) Contact Provides High Reliability And Low Resistance |
| Gender | Female-Male |
| Gross Weight | 0 lbs. |
| Ip Rating | IP67, IP68 |
| Jacket Color | Yellow |
| Jacket Material | PVC |
| Keyway Type | Single |
| Led Indicator | No |
| Length | 6 ft. |
| Max. Amps | 8A |
| Max. Amps Per Contact | 8A |
| Max. Operating Temp. | 221°F |
| Max. Voltage | 600V AC/DC , 600V DC/600V AC |
| Min. Operating Temp. | -4°F |
| Nema Rating | NEMA 6P |
| No. Of Wires | 6 |
| Orientation | Straight To Straight |
| Plating Mating Material | Gold |
| Voltage | 600V |
Shipping Info:
| Ship weight (kg) | 0.5 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | MX |
Product Variants
| Model | Cable Length | End 1 Mounting Orientation | End 2 Connection | End 1 Connection | End Connection Type 2 | Max. Amps | Max. Voltage | End 1 No. Of Pins | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 104002A01F060 | 6 ft. | Straight | Bare Wire | 7/8" Male | Bare Wire | 10A | 600V AC/DC | 4 | €51.87 | |
| 103001A01F200 | 20 ft. | Right Angle | Bare Wire | 7/8" Female | Bare Wire | 13A | 600V AC/DC | 3 | €71.93 | |
| 105001A01F200 | 20 ft. | Right Angle | Bare Wire | 7/8" Female | Bare Wire | 8A | 600V AC/DC | 5 | €109.99 | |
| 102000A01F060 | 6 ft. | Straight | Bare Wire | 7/8" Female | Bare Wire | 13A | 600V AC/DC | 2 | €49.62 | |
| 102000A01F120 | 12 ft. | Straight | Bare Wire | - | Bare Wire | 13A | 600V AC/DC | 2 | €57.30 | |
| 102002A01F060 | 6 ft. | Straight | Bare Wire | 7/8" Male | Bare Wire | 13A | 600V AC/DC | 2 | €38.95 | |
| 102002A01F120 | 12 ft. | Straight | Bare Wire | 7/8" Male | Bare Wire | 13A | 600V AC/DC | 2 | €53.04 |
