BOSTON GEAR NH20B-1 1/8 Spur Gear, 8 Diametral Pitch, 14 1/2 Deg. Pressure Angle, 20 Teeth, Steel
Item: AK3CACModel: NH20B-1 1/8
7 In Stock
Ships within 2 days via
€274.56 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Spur Gear |
| Bore Dia. | 1 1/8" |
| Diametral Pitch | 8" |
| Face Width | 1 1/4" |
| Hub Dia. | 2.05" |
| Hub Projection | 3/4" |
| Keyway Size | 1/4" x 1/8" |
| Material | Steel |
| No. Of Teeth | 20 |
| Output Dia. | 2 3/4" |
| Overall Length | 2" |
| Pitch Dia. | 2 1/2" |
| Pressure Angle | 14.5° |
| Product Datasheet | boston-gear-g101.pdf |
| Type | Plain |
Shipping Info:
| Ship weight (kg) | 1.35 |
| Ship length (cm) | 5.08 |
Documentation:
Product Variants
| Model | Diametral Pitch | Bore Dia. | Pitch Dia. | Hub Dia. | Hub Projection | Number Of Teeth | Outside Dia. | Overall Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| NH18 B | 8 | 7/8" | 2 1/4" | 1 4/5" | 0.75" | 18 | 2 1/2" | 2" | €206.58 | |
| NH24A | 8 | 7/8" | 3" | 2.06" | 0.88" | 24 | 3 1/4" | 2.13" | €292.22 | |
| NH32A | 8 | 1" | 4" | 3" | 0.88" | 32 | 4 1/4" | 2.13" | €386.83 | |
| NH11B | 8 | - | - | - | - | - | - | - | €128.97 | |
| NH12B | 8 | - | - | - | - | 12 | - | - | €128.97 | |
| NH15B | 8 | - | - | - | - | 15 | - | - | €160.36 | |
| NH16B | 8" | 7/8" | 2" | 1.55" | 3/4" | - | - | 2" | €164.07 |
