BOSTON GEAR D1434 RH RH Cast Iron Worm Gear
€858.94 /unit
Request a Quote
Payment
Delivery
Product Specifications:
| Bore Dia. | 1 1/4" |
| Bore Size | 1 1/4" , 1.25" |
| Diametral Pitch | 6 |
| Face Width | 1" |
| Flush Face To Worm Centerline | 0.5 |
| Gear Construction | Webbed With Lightening Holes |
| Hardened Teeth | Without Hardened Teeth |
| Helix Angle | 9.4667° |
| Hub Dia. | 2.94" |
| Keyway | No KWY Or Setscrew , No KWY, Setscrew |
| Left/right Hand | Right Hand |
| Length Through Bore | 2" |
| Material | Cast Iron |
| No. Of Leads | 2 , Double |
| No. Of Teeth | 72 |
| No. Of Threads | 4 , Quad Thread |
| Pitch | 6" |
| Pitch Dia. | 12" |
| Pressure Angle | 14.5° |
Product Variants
| Product | Model | Pitch Dia. | No. Of Teeth | Hub Dia. | Face Width | Diametral Pitch | No. Of Threads | Length Through Bore | Bore Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
D620A RH | 3.333" | 20 | 2" | 1" | 6 | 2 , 4 | 1 22/25" | 1" | €300.47 | |
 |
D660 RH | 10" | 60 | 2.69" | - | 6 | 4 , Quad Thread | 2" | 1 1/4" , 1.25" | €755.53 | |
 |
D1260A RH | 5" | 60 | 1.69" | 1/2" | 12 | 4 , Quad Thread | 1 1/4" , 1.25" | 0.75" , 3/4" | €242.67 | RFQ
|
 |
D1404 RH | 6.667" | 80 | 1.94" | 1/2" | 12 | 4 , Quad Thread | 1 1/4" , 1.25" | 0.75" , 3/4" | €278.07 | RFQ
|
 |
G8100ARH | 12 1/2" | 100 | 2.69" | 3/4" | - | 1 | - | - | €647.78 |
