BALDOR MOTOR CFDL3504M Farm Duty Motor, 115/230V, 1800 RPM, 0.5 hp, 1 Phase, TEFC, 56C Frame
Get it by Tuesday, Dec 23
€1,139.03 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Farm Duty Motor |
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 7.4/3.7A |
| Amps @ 208v | 4.3A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 4.13 lbs.-ft. |
| Class | Stock |
| Code | J |
| Conduit Box Position | F1 |
| Design Code | N |
| Duty | Continuous |
| Enclosure Design | TEFC |
| Frame | 56C |
| Frame Material | Steel |
| Frame Size | 56C |
| Frequency | 60 Hz |
| Full Load Torque | 1.5 lbs.-ft. |
| Full Load Torque | 1.5 ft.-lbs. |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Inverter Code | Not Inverter |
| Lead | 6#18,1#16 #4TH |
| Lead | 6#18, 1#16 #4Th |
| Line-line Res. @ 25° C | 4.44 ohms A Ph/3.19 ohms B Ph |
| Locked-rotor Torque | 4.65 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Type | Capacitor Start/Induction Run |
| Multiplier | K |
| Nema/iec | NEMA |
| No Load Amps | 2.8A |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 68% |
| Overall Length | 11.97" |
| Phase | 1 |
| Power Factor | 66 |
| Product Datasheet | baldor-motor-cfdl3504m.pdf |
| Proprietary | No |
| Pull-up Torque | 3.6 lbs.-ft. |
| Pulley Face Code | C Face |
| Revision | U |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 16.5A |
| Synchronous Rpm | 1800 RPM |
| Temp. Rise | 77°C |
| Temp. Rise @ Rated Load | 63°C |
| Temp. Rise @ S. F. Load | 77°C |
| Thermal Protection | Manual |
| Type | 3421L |
| Voltage | 115/230V |
| Wire Size | 18 AWG |
Shipping Info:
| Ship weight (kg) | 12.6 |
| Ship height (cm) | 28.26 |
| Ship length (cm) | 41.91 |
| Ship width (cm) | 29.21 |
| HS code | 85013100 |
| Country of Origin | US |
Product Details:
- Explosion Proof Class/Group: NONE
- Locked-Rotor Torque: 4.65 LB-FT
- Nameplate No.: NP1280L
- Pull-Up Torque: 3.6 LB-FT
- Starting Current: 16.5 Amps
