ASHCROFT A2XBF0215C25#G Pressure Transmitter, 0 to 5 PSI, 1 to 5V DC, Cable & Wire Leads, IP65 /4X/IP65 /7/IP65 /9
Item: AE4LZEModel: A2XBF0215C25#GCross Ref: 5LRH7
7 In Stock
Ships within 2 days via
10.00% off
€842.02 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | XP Pressure Transducer |
| Accuracy | -0.5% to +0.5% |
| Burst Pressure | 2x Range |
| Cable Length | 3 ft. |
| Compatible With | Any Process Compatible With 316 Stainless Steel |
| Electrical Connection | Cable & Wire Leads, 1/2" Fnpt Conduit Connection Entry |
| Electrical Connections | Cable & Wire Leads |
| Enclosure Rating | IP65, NEMA 4X, NEMA 7, NEMA 9 |
| Explosion/fire Proof | Yes |
| Features | Ashcroft’S Proven Thin Film Technology |
| Fitting Material | Stainless Steel |
| Housing Material | Stainless Steel |
| Ip Rating | IP65 |
| Manufacturers Warranty Length | 1 yr. |
| Material | Stainless Steel |
| Max. Pressure | 10 psi |
| Maximum Operating Temperature | 257°F |
| Maximum Pressure | 5 psi |
| Minimum Operating Temperature | -40°F |
| Minimum Pressure | 0 psi |
| Nema Rating | NEMA 4X, NEMA 7, NEMA 9 |
| Number Of Wires | 3 |
| Operating Temp. | -40°F to +257°F |
| Output | 1-5V DC |
| Output Voltage | 1-5V DC |
| Overall Height | 4.78" |
| Overall Length | 1.06" |
| Overall Width | 1.06" |
| Overpressure | 1.5 x Range |
| Power Required | 10-36V DC |
| Pressure Range | 0 psi to 5 psi |
| Pressure Units | Psi |
| Process Connection | 1/4" NPT Female |
| Process Connection Gender | Female |
| Process Connection Size | 1/4" |
| Process Connection Type | NPT |
| Product Type | Explosion-Proof-Rated Transmitter |
| Range | 0 psi to 5 psi |
| Response Time | 2 ms |
| Safety Rating | Class I, II And III Div. 1 And 2 Groups A, B, C, D, F And G |
| Series | A2X Series |
| Storage Temperature Range | -40°F to +257°F |
| Thermal Error | -2% to +2% |
| Wiring Entry | 1/2" FNPT Conduit Connection |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 12.14 |
| Ship length (cm) | 2.69 |
| Ship width (cm) | 2.69 |
| HS code | 9026204000 |
| Country of Origin | US |
Product Variants
| Model | Power Required | Accuracy | Output | Number Of Wires | Nema Rating | Pressure Range | Process Connection | Housing Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| A2XBF0442C25#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 5 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C215#G&VAC | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | -14.7 psi to +15 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C215#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 15 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C230#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 30 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C260#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 60 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C2100#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 100 psi | 1/2" NPT Female | Stainless Steel | €857.13 | |
| A2XBF0442C2200#G | 12-30V DC | -0.5% to +0.5% | 4-20 mA | 2 | NEMA 4X, NEMA 7, NEMA 9 | 0 psi to 200 psi | 1/2" NPT Female | Stainless Steel | €857.13 |
