ASHCROFT 601082PS04L5000# Pressure Gauge, 0 to 5000 PSI, Grade 3A - Test, 6 Inch Dial, 1/2 Inch NPT Male, Bottom
Item: CN8YGWModel: 601082PS04L5000#Cross Ref: 787ML0
7 In Stock
Ships within 2 days via
10.00% off
€627.49 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Gauge |
| Accuracy | -0.25% to +0.25% |
| Accuracy Grade | ASME B40.1 Grade 3A |
| Application | Calibration Labs, Medical And Life Sciences, Specialized OEM Equipment, Test Benches, Test Measurement And Validation |
| Case Color | Black |
| Case Material | Aluminum |
| Connection Location | Bottom |
| Gauge Accuracy Grade | Grade 3A Test |
| Gauge Case Material | Aluminum |
| Ip Rating, Nema Rating | Not Rated |
| Lens Material | Glass |
| Nominal Dial Size | 6" |
| Pressure Gauge Type | Test Pressure Gauge |
| Pressure Range | 0 psi to 5000 psi |
| Primary Range | 0 to 5000 |
| Primary Scale Units | Psi |
| Primary Units | psi |
| Process Connection | 1/2" NPT Male |
| Process Connection Gender | Male |
| Process Connection Location | Bottom |
| Process Connection Size | 1/2" |
| Process Connection Type | NPT |
| Process Temperature Range | -20°F to +200°F |
| Sensor Material | Monel |
| Series | 1082 Series |
| Socket Material | Monel |
Shipping Info:
| Ship weight (kg) | 1.8 |
| Ship height (cm) | 16.51 |
| Ship length (cm) | 16.51 |
| Ship width (cm) | 7.62 |
| Country of Origin | US |
Product Variants
| Model | Nominal Dial Size | Pressure Range Type | Pressure Range | Mounting Type | Socket Material | Sensor Material | Primary Scale Units | Process Temperature Range | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 45-1082AS 02L 100 PSI | 4 1/2" | Pressure | 0 psi to 100 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 15 | 4 1/2" | Pressure | 0 psi to 15 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 200 PSI | 4 1/2" | Pressure | - | - | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 30 PSI | 4 1/2" | Pressure | 0 psi to 30 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 300 PSI | 4 1/2" | Pressure | 0 psi to 300 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 400 PSI | 4 1/2" | Pressure | 0 psi to 400 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 | |
| 45-1082AS 02L 60 PSI | 4 1/2" | Pressure | 0 psi to 60 psi | Flush Mount | Brass | Bronze | Psi | -20°F to +250°F | €434.35 |
