ASHCROFT 10N5500SL04L4# Low Pressure Gauge, 0 to 4 PSI, 100 mm Dial, 1/2 Inch NPT Male, Bottom, ±1.6% Accuracy
Item: CN8XVUModel: 10N5500SL04L4#Cross Ref: 787MK6
7 In Stock
Ships within 2 days via
10.00% off
€454.29 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Gauge |
| Accuracy | -1.6% to +1.6% |
| Application | Chemical And Petrochemical Plants, Equipment Skids, Oil And Gas, Water And Wastewater Pressure Control |
| Case Color | Stainless Steel |
| Case Grade | Grade 304 |
| Case Material | Stainless Steel |
| Gauge Case Material | Stainless Steel |
| Gauge Case Material Grade | Grade 304 |
| Grade | Grade 316Ti |
| Includes | Vent Plug |
| Ip Rating, Nema Rating | Not Rated |
| Lens Material | Glass |
| Lens Material - Gauge | Glass |
| Material | Stainless Steel |
| Mfr. Series | N5500 Series |
| Nominal Dial Size | 100 mm |
| Pressure Gauge Type | Low Pressure Gauge |
| Pressure Range | 0 psi to 4 psi |
| Pressure Range Type | Pressure |
| Primary Pressure Range | 0 psi to 4 psi |
| Primary Scale Units | Psi |
| Process Connection | 1/2" NPT Male |
| Process Connection Gender | Male |
| Process Connection Location | Bottom |
| Process Connection Size | 1/2" |
| Process Connection Type | NPT |
| Process Temperature Range | +13°F to +140°F |
| Sensor Grade | Grade 316TI |
| Sensor Material Grade | Grade 316Ti , Stainless Steel |
| Sensor Type | 316TI Stainless Steel |
| Socket Material | Stainless Steel |
Shipping Info:
| Ship weight (kg) | 0.79 |
| Ship height (cm) | 10.92 |
| Ship length (cm) | 10.92 |
| Ship width (cm) | 6.35 |
| Country of Origin | DE |
Product Variants
| Model | Pressure Range | Primary Scale Units | Primary Pressure Range | Pressure Gauge Type | Pressure Range Type | Process Connection Location | Nominal Dial Size | Case Color | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 10N5500SD04L10IW | 0 in. H2O to 10 in. H2O | in. h2o | 0 psi to 10 psi | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SD04L25IW | 0 in. H2O to 25 in. H2O | in. h2o | 0 psi to 25 psi | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SD04L4# | 0 psi to 4 psi | Psi | 0 psi to 4 psi | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SL04L40IW | 0 in. H2O to 40 in. H2O | in. h2o | 0 psi to 40 psi | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SD04L40IW | 0 in. H2O to 40 in. H2O | in. h2o | 0 psi to 40 psi | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SD04L6# | 0 psi to 6 psi | Psi | 0 to 6 | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 | |
| 10N5500SL04L6# | 0 psi to 6 psi | Psi | 0 to 6 | Low Pressure Gauge | Pressure | Bottom | 100 mm | Stainless Steel | €504.77 |
