APPROVED VENDOR 6UED3 Fan And Limit 170-190 Temperature Range
Item: AF2HXRModel: 6UED3
7 In Stock
Ships within 2 days via
10.00% off
€14.40 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Snap Disc Control |
| Application | Limit Control With Fan Bypass |
| Circuit #1 Switch Closes @ (f) | 170°F |
| Circuit #1 Switch Closes @ (f) | 170 |
| Circuit #1 Switch Opens @ (f) | 190°F |
| Circuit #1 Switch Opens @ (f) | 190 |
| Contact Form | SPDT |
| Depth | 1" |
| Face Diameter | 2" |
| Height | 1 1/2" |
| Inductive Amps @ 120v | 10 |
| Inductive Amps @ 240v | 5 |
| Inductive Amps @ 240v | 5A |
| Input Voltage | 120/277V AC |
| Ip Rating | Not Rated |
| Mounting | Surface Mount |
| Mounting Base Length | 2" |
| Mounting Base Width | 1 5/8" |
| Mounting Hole Center To Center Distance | 1 5/8" |
| Mounting Hole Diameter | 1/8" |
| Number Of Mounting Holes | 2 |
| Overall Depth | 1" |
| Overall Height | 1 1/2" |
| Pilot Contact Rating | 125 VA |
| Pilot Duty Contacts (va) | 125 |
| Pilot Duty Contacts (va) | 125 VA |
| Product Type | Temperature Limit Controller |
| Reset Type | Automatic Reset |
| Resistive Amps @ 120v | 25 |
| Resistive Amps @ 120v Ac | 25A |
| Resistive Amps @ 240v Ac | 25A |
| Resistive Amps @ 277v | 21.6 |
| Resistive Amps @ 277v | 21.6A |
| Standards | Culus Recognized |
| Switch Action | Open Closes On Rise |
| Switch Closing Temperature | 170°F, 190°F |
| Switch Opening Temperature | 170°F, 190°F |
| Switch Type | SPDT |
| Temp. Range | +170°F to +190°F |
| Temperature Differential | 20°F |
| Terminal Size | 1/4" |
| Type | Fan And Limit |
| Voltage | 120-277V AC |
| Voltage Range | 120-277V |
| Weight | 0.9 oz. |
| Width | 1 3/4" |
| Wire Connections | Spade terminals |
Shipping Info:
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 3.81 |
| HS code | 8536509055 |
| Country of Origin | CN |
Product Details:
- Circuit #2 Switch Closes @ (F) (190)
- Circuit #2 Switch Opens @ (F) (170)
- Circuit No. 1-Inductive 120V (10)
- Circuit No. 1-Inductive 240V (5)
- Circuit No. 2-Inductive 120V (5.8)
- Circuit No. 2-Inductive 240V (2.9)
- Resistive Rating 240V (25)
Product Variants
| Product | Model | Circuit #1 Switch Opens @ (f) | Circuit #1 Switch Closes @ (f) | Switch Action | Voltage | Height | Depth | Inductive Amps @ 240v | Pilot Duty Contacts (va) | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6UED2 | 140°F | 120°F | Open Closes On Rise | 120-277V AC | 1 1/2" | 1" | 5A | 125 VA | €16.01 |
