3M FP301-1/16-1000 -BLUE-SPOOL Heat Shrink Tubing, 1000 Feet, Thin Wall, Flexible Polyolefin, Shrink Ratio 2:1
Item: CF2AVKModel: FP301-1/16-1000 -BLUE-SPOOLCross Ref: 2JPR7
7 In Stock
Ships within 2 days via
10.00% off
€2,210.60 /pkg. of 3
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Heat Shrink Tubing |
| Adhesive Lined | No |
| Color | Blue |
| Dielectric Strength | 900V |
| Features | Balances Electrical, Physical And Chemical Properties, Shrink Fit Protection, Solder Joints, Strain Relief, Terminals And Connections |
| Flame Retardant | Yes |
| I.d. After Shrinking | 0.03" |
| I.d. Before Shrinking | 0.06" |
| Length | 1000 ft. |
| Length (straight Wireway) | 1000 ft. |
| Material | Polyolefin |
| Max. Temp. Rating | 275°F |
| Max. Voltage | 600V |
| Min. Shrink Temp. | 212°F |
| Min. Temp. Rating | -67°F |
| Package Style | Cut To Length |
| Shrink Ratio | 2:1 |
| Shrink Tube Material Type | Flexible |
| Shrink Tubing Adhesive Lined | No |
| Shrink Tubing I.d. Before Shrinking | 0.063" |
| Shrink Tubing Length | 1000 ft. |
| Shrink Tubing Properties | Acid And Alkali Resistant, Solvent Resistant |
| Shrink Tubing Wall Type | Thin Wall |
| Temp. Range | -67°F to +275°F |
| Tubing Wall Type | Thin Wall |
| Use With Wire Size | 28 AWG to 26 AWG |
| Wall Thickness After Shrinking | 0.02" |
| Wall Type | Thin Wall |
Shipping Info:
| Ship weight (kg) | 4.28 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 0.18 |
| Ship width (cm) | 0.18 |
| Country of Origin | US |
Product Variants
| Model | I.d. Before Shrinking | Wall Thickness After Shrinking | Color | I.d. After Shrinking | Shrink Ratio | Temp. Range | Min. Shrink Temp. | Adhesive Lined | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SFTW-203 1/8 PK25 | 0.12" | 0.02" | Black | 0.04" | 3:1 | -67°F to +275°F | 212°F | No | 25 | €138.23 | |
| SFTW-203 1/4 PK12 | 0.24" | 0.03" | Black | 0.08" | 3:1 | -67°F to +275°F | 212°F | No | 12 | €166.72 | |
| SFTW-203 3/8 PK12 | 0.35" | 0.03" | Black | 0.12" | 3:1 | -67°F to +275°F | 212°F | No | 12 | €182.96 | |
| SFTW-203 1/2 PK12 | 0.47" | 0.03" | Black | 0.16" | 3:1 | -67°F to +275°F | 212°F | No | 12 | €136.35 | |
| SFTW-203 3/4 PK12 | 0.71" | 0.03" | Black | 0.24" | 3:1 | -67°F to +275°F | 212°F | No | 12 | €261.16 | |
| SFTW-203 1 PK5 | 0.95" | 1/25" | Black | 0.32" | 3:1 | -67°F to +275°F | 212°F | No | 5 | €172.30 | |
| SFTW-203 1 1/2 PK5 | 1.54" | 0.05" | Black | 0.51" | 3:1 | -67°F to +275°F | 212°F | No | 5 | €228.92 |
