3M 7000031408 31153 Two-Hole Lug Compression Connector, 300 kcmil Max Wire Size, 1/2 Inch Stud Size
Item: AB9KUYModel: 7000031408Cross Ref: 2DRE5 / 31153
7 In Stock
Ships within 2 days via
10.00% off
€404.92 /pkg. of 10
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Copper 2-Hole L-Barrel Lug |
| Barrel Inside Dia. | 0.65" |
| Barrel Outside Diameter | 0.81" |
| Barrel Size | Long |
| Barrel Style | Seamless |
| Cable Size | 300 kcmil |
| Cable Size Code | 300 kcmil |
| Center Of Hole To Center Of Hole | 1 3/4" |
| Center Of Hole To End Of Pad | 0.63" |
| Color Code | White |
| Connector Description | Two Hole |
| Connector Type | Straight Barrel |
| Contact Finish | Tin |
| Die Code | 17 |
| For Conductor Material | Copper |
| For Max. Stranded Copper Wire Size | 300 kcmil |
| For Stud Size | 1/2" |
| For Use With | Copper Conductor Only |
| For Wire Size | 300 kcmil |
| For Wire Type | Stranded |
| Hole Center To Center | 1 3/4" |
| Hole Center To End | 0.63" |
| Hole To Hole Center | 1.75" |
| Hole To Hole Center (in.) | 1.750 |
| Inspection Hole | No |
| Length | 5 3/4" |
| Length (straight Wireway) | 5 3/4" |
| Lug Compression Connector Type | Two-Hole Lug Compression Connector |
| Lug Type | Compression Lugs |
| Material | Copper |
| Max. Operating Voltage | 35 kV |
| Maximum Voltage | 35 kV AC |
| Maximum Wire Size | 300 kcmil |
| Number Of Holes | 2 |
| Number Of Stud Holes | 2 |
| Overall Length | 5.75" |
| Overall Width | 1.22" |
| Peep Hole | No |
| Plate Material | Tin |
| Rohs Compliant | Yes |
| Seam Style | Seamless |
| Special Features | Corrosion Resistance, Good Conductivity, Reliable Performance, Secure Fit |
| Stud Size | 1/2" |
| Termination Style | Crimp |
| Tongue Angle | Straight |
| Tongue Length | 3" |
| Tongue Style | Standard |
| Tongue Width | 1.22" |
| Type | Standard |
| Width | 1.22" |
| Wire Size Range | 300 kcmil |
Shipping Info:
| Ship weight (kg) | 1.53 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 14.61 |
| Ship width (cm) | 3.1 |
| HS code | 8535908040 |
| Country of Origin | CL |
Product Variants
| Product | Model | Color Code | Cable Size | Overall Length | Cable Size Code | Connector Type | Stud Size | Material | Peep Hole | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
7000031445 | Blue | 400 kcmil | 6" | 400 kcmil | Straight Barrel | 1/2" | Copper | No | 10 | €560.71 | |
 |
7000031409 | Red | 350 kcmil | 5.75" | 350 kcmil | Straight Barrel | 1/2" | Copper | No | 10 | €484.12 | |
 |
7000031406 | Purple | - | 5.16" | - | Straight Barrel | 1/2" | Copper | No | 10 | €397.43 | |
 |
7000005882 | Brown | 500 kcmil | 6.16" | 500 kcmil | Straight Barrel | 1/2" | Copper | No | 10 | €574.06 | |
 |
7000031447 | Green | 600 kcmil | 6.72" | 600 kcmil | Straight Barrel | 1/2" | Copper | No | 6 | €665.47 | |
 |
7000031410 | Black | 750 kcmil | 7" | 750 kcmil | Straight Barrel | 1/2" | Copper | No | 6 | €846.68 | |
 |
7000031411 | White | 1000 kcmil | 7.28" | 1000 kcmil | Straight Barrel | 1/2" | Copper | No | 6 | €1,147.18 |
