3M 7000058006 80610253694 / 09233 / 314U-BIN Insulation Displacement Connector, White, Pigtail, 3 Ports
Item: AB9LAPModel: 7000058006Cross Ref: 2DTN5 / 80610253694 / 09233 / 314U-BIN
7 In Stock
Ships within 2 days via
10.00% off
€810.77 /pkg. of 1000
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Insulation Disp. Connector |
| Application | Dry Environment |
| Color | White |
| Compatible Installation Tool Model Number | E-9BM |
| Compatible With Product Type | Luminaries |
| Connector Type | Pigtail |
| Contact Finish | Tin |
| Contact Material | Brass |
| Crimping Tool | 2JLF8 |
| Fill Material | No Fill |
| Flame Retardant | Yes |
| Insulation Material | Nylon |
| Material | Nylon |
| Max. Insulation Dia. | 0.155" |
| Max. Temp. | 221°F |
| Max. Voltage | 600V |
| Maximum Insulation Diameter | 0.155" |
| Maximum Run Wire Insulation Diameter | 0.155" |
| Maximum Run Wire Size | 14 AWG |
| Maximum Tap Wire Insulation Diameter | 0.155" |
| Maximum Tap Wire Size | 14 AWG |
| Minimum Run Wire Size | 22 AWG |
| Minimum Tap Wire Size | 22 AWG |
| No. Of Ports | 3 |
| Number Of Ports | 3 |
| Rohs Compliant | Yes |
| Run Wire Size Range | 22 AWG to 14 AWG |
| Special Features | Self Stripping |
| Tap Wire Size Range | 22 AWG to 14 AWG |
| Type | Dry Environment |
| Wire Range | 22 AWG to 14 AWG |
| Wire Type | Electrical |
Shipping Info:
| Ship weight (kg) | 3.47 |
| Ship height (cm) | 10.16 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 20.32 |
| HS code | 8536904000 |
| Country of Origin | US |
Product Variants
| Product | Model | Color | Fill Material | Number Of Ports | Connector Type | Insulation Material | Max. Voltage | Flame Retardant | Wire Type | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
7000031482 | Blue | Gel | 3 | Pigtail | Nylon | 600V | Yes | Electrical | 1000 | €2,153.69 |
