MERSEN FERRAZ Protistor fuses, 690VAC/700VAC

Filter

Style	Model	Amps	Mounting	Connection/terminal Type	Connection/terminal Material	Speed Characteristic	Ac Max. I R Breaking Capacity I1	Power Dissipation @ Rated Amps Value	Clearing I2t @ Rated Voltage	Pkg. Qty.	Price
A	X1017195	1A	Clip	Ferrule	Copper	GR	160 kA	1.15 W	0.3 sq. A sec.	10	€1,003.99
B	Y1017196	2A	Clip	Ferrule	Copper	GR	160 kA	1.75 W	1.8 sq. A sec.	10	€1,005.32
C	Z1017197	4A	Clip	Ferrule	Copper	GR	160 kA	2.9 W	13 sq. A sec.	10	€1,149.32
D	A1017198	6A	Clip	Ferrule	Copper	GR	160 kA	2 W	35 sq. A sec.	10	€1,005.32
E	F1017180	6A	Clip	Ferrule	Copper	GR	160 kA	2 W	35 sq. A sec.	10	€1,600.76
F	B1017199	8A	Clip	Ferrule	Copper	GR	160 kA	2.25 W	40 sq. A sec.	10	€1,005.32
G	C1017200	10A	Clip	Ferrule	Copper	GR	160 kA	2.95 W	45 sq. A sec.	10	€1,005.32
H	D1017201	12A	Clip	Ferrule	Copper	GR	160 kA	4.1 W	60 sq. A sec.	10	€1,005.32
I	T1056660	16A	Clip	Ferrule	Copper	AR	160 kA	5 W	100 sq. A sec.	1	€143.96
J	E1017202	16A	Clip	Ferrule	Copper	GR	160 kA	4.65 W	125 sq. A sec.	10	€947.63
K	A320137	20A	Clip	Plain Blades	Brass	AR	170 kA	2.8 W	90 sq. A sec.	3	€543.07
L	F1017203	20A	Clip	Ferrule	Copper	GR	160 kA	4.8 W	230 sq. A sec.	10	€1,005.32
K	C320139	25A	Clip	Plain Blades	Brass	AR	170 kA	4.2 W	130 sq. A sec.	3	€891.87
M	G1017204	25A	Clip	Ferrule	Copper	GR	160 kA	5.95 W	385 sq. A sec.	10	€1,005.32
K	G320143	32A	Clip	Plain Blades	Brass	AR	170 kA	5.5 W	270 sq. A sec.	3	€936.50
N	H1017205	32A	Clip	Ferrule	Copper	GR	160 kA	6.9 W	700 sq. A sec.	10	€1,005.32
O	Y320043	32A	Clip	Plain Blades	Brass	AR	80 kA	5.5 W	270 sq. A sec.	3	€776.71
K	Q320243	32A	Clip	Plain Blades	Brass	AR	170 kA	19.4 W	170 sq. A sec.	3	€1,586.22
P	S1017191	40A	Clip	Ferrule	Copper	GR	160 kA	7.5 W	1050 sq. A sec.	10	€1,699.24
K	L320147	40A	Clip	Plain Blades	Brass	AR	170 kA	8.3 W	400 sq. A sec.	3	€936.50
K	V320247	40A	Clip	Plain Blades	Brass	AR	170 kA	20.8 W	280 sq. A sec.	3	€1,586.22
Q	J1017206	40A	Clip	Ferrule	Copper	GR	160 kA	7.5 W	1050 sq. A sec.	10	€1,699.63
K	Z320251	50A	Clip	Plain Blades	Brass	AR	170 kA	20.8 W	470 sq. A sec.	3	€1,586.22
R	G320051	50A	Clip	Plain Blades	Brass	AR	80 kA	9.7 W	630 sq. A sec.	3	€830.06
S	K1017207	50A	Clip	Ferrule	Copper	GR	160 kA	8.75 W	2250 sq. A sec.	10	€1,699.63
T	A301921	50A	Bolted	Slotted Blades	Copper	AR	200 kA	9 W	0.68 sq. kA sec.	1	€494.46
K	Q320151	50A	Clip	Plain Blades	Brass	AR	170 kA	9.7 W	630 sq. A sec.	3	€936.50
U	L1017208	63A	Clip	Ferrule	Copper	GR	160 kA	12.5 W	2900 sq. A sec.	10	€1,699.63
K	V320155	63A	Clip	Plain Blades	Brass	AR	170 kA	12.5 W	1300 sq. A sec.	3	€936.50
V	M320355	63A	Clip	Plain Blades	Brass	AR	170 kA	36.1 W	700 sq. A sec.	3	€2,150.99
W	L320055	63A	Clip	Plain Blades	Brass	AR	80 kA	12.5 W	1300 sq. A sec.	3	€830.06
X	F1056671	63A	Clip	Ferrule	Copper	AR	160 kA	15.5 W	3100 sq. A sec.	1	€269.12
Y	A301967	63A	Bolted	Flush Ends	Brass	AR	200 kA	14 W	1.2 sq. kA sec.	1	€428.92
K	Z320159	80A	Clip	Plain Blades	Brass	AR	170 kA	16.7 W	2000 sq. A sec.	3	€1,001.40
Z	K320399	80A	Clip	Plain Blades	Brass	AR	170 kA	43 W	1170 sq. A sec.	3	€2,150.99
K	D320163	100A	Clip	Plain Blades	Brass	AR	170 kA	19.4 W	4300 sq. A sec.	3	€953.69
K	M320263	100A	Clip	Plain Blades	Brass	AR	170 kA	30.5 W	2080 sq. A sec.	3	€1,680.78
A1	W320363	100A	Clip	Plain Blades	Brass	AR	170 kA	45.8 W	1570 sq. A sec.	3	€2,150.99
B1	V320063	100A	Clip	Plain Blades	Brass	AR	80 kA	19.4 W	4300 sq. A sec.	3	€830.06
K	P320265	125A	Clip	Plain Blades	Brass	AR	170 kA	36.1 W	3890 sq. A sec.	3	€1,680.78
C1	Y320365	125A	Clip	Plain Blades	Brass	AR	170 kA	53 W	3320 sq. A sec.	3	€2,282.90
D1	F320165	125A	Clip	Plain Blades	Brass	AR	170 kA	20.8 W	8200 sq. A sec.	3	€1,001.40
E1	X320065	125A	Clip	Plain Blades	Brass	AR	80 kA	20.8 W	8200 sq. A sec.	3	€830.06
F1	F300385	160A	Bolted	Slotted Blades	Copper	AR	200 kA	35 W	7700 sq. A sec.	1	€638.24
G1	M300299	160A	Bolted	Flush Ends	Brass	AR	200 kA	35 W	7700 sq. A sec.	3	€2,012.12
H1	M300322	160A	Bolted	Din 80 Blades	Copper	AR	200 kA	35 W	7700 sq. A sec.	3	€1,842.03
K	T320269	160A	Clip	Plain Blades	Brass	AR	170 kA	44.4 W	8320 sq. A sec.	3	€1,680.78
K	K320169	160A	Clip	Plain Blades	Brass	AR	170 kA	30.5 W	12200 sq. A sec.	3	€1,001.40
I1	L320469	160A	Clip	Plain Blades	Brass	AR	170 kA	75 W	5.18 sq. kA sec.	3	€2,605.56
F1	S300028	200A	Bolted	Slotted Blades	Copper	AR	200 kA	45 W	15000 sq. A sec.	1	€557.24
J1	N320471	200A	Clip	Plain Blades	Brass	AR	170 kA	83 W	9.22 sq. kA sec.	3	€2,605.56
K	M320171	200A	Clip	Plain Blades	Brass	AR	170 kA	36.1 W	22700 sq. A sec.	3	€1,097.43
K1	H300019	200A	Bolted	Din 110 Blades	Copper	AR	200 kA	45 W	15000 sq. A sec.	3	€1,980.00
L1	N300001	200A	Bolted	Flush Ends	Brass	AR	200 kA	45 W	15000 sq. A sec.	3	€1,994.97
M1	C300037	200A	Bolted	Open Slot Blades	Copper	AR	200 kA	45 W	15000 sq. A sec.	3	€1,827.38
N1	V300697	200A	Bolted	Slotted Blades	Copper	AR	200 kA	45 W	15000 sq. A sec.	1	€605.00
O1	Y300010	200A	Bolted	Din 80 Blades	Copper	AR	200 kA	45 W	15000 sq. A sec.	3	€1,825.20
P1	A300472	200A	Bolted	Flush Ends	Brass	AR	200 kA	45 W	15000 sq. A sec.	1	€580.81
K	W320271	200A	Clip	Plain Blades	Brass	AR	170 kA	54.2 W	15900 sq. A sec.	3	€1,680.78
Q1	S320475	250A	Clip	Plain Blades	Brass	AR	170 kA	93 W	18.7 sq. kA sec.	3	€2,790.33
K	A320275	250A	Clip	Plain Blades	Brass	AR	170 kA	66.7 W	29900 sq. A sec.	3	€1,925.00
