CONRADER Throttle Control Engine


Conrader throttle controls are ideal for controlling the engine speed in gas engine-powered compressors during continuous run operations. They can save fuel and increase the operating life of the compressor & engine. These air compressor throttle controls are used with a pilot valve & a...n unloader valve. Read more

Filter
CONRADER TCSP-H-5565-BA
CONRADER TCSA-5565S-SCB
CONRADER TCSP-H-0809-BC
CONRADER TCSP-H-1113-BD
CONRADER TCXLIW-CH440E
CONRADER TCXLPW-48F
StyleModelMin. Operating PressureInlet Connection TypeInlet SizeCable LengthCable Material(m)npt Size (in.)Cylinder MaterialO-ring MaterialPrice
A
TCSP-H-5565-B		40 psiCompression Tube1/4"-Stainless Steel0.25"BrassViton€35.63
B
TCSA-5565S-SC		40 psiCompression Tube1/4"-Stainless Steel0.125"BrassViton€24.54
C
TCSP-H-0809-B		40 psi---Stainless Steel0.25"BrassViton€45.87
D
TCSP-H-1113-B		40 psiCompression Tube1/4"-Stainless Steel0.25"BrassViton€45.50
E
TCXLIW-CH440		100 psiNPT1/8"3"Stainless Steel0.125"BrassViton€61.17
F
TCXLPW-48		100 psi--48"Filled Nylon0.125"BrassViton€60.00
F
TCXLPW-24		100 psiNPT1/8"24"Stainless Steel0.125"BrassViton€54.12
F
TCXLPW-36		100 psiNPT1/8"36"Stainless Steel0.125"BrassViton€57.65
F
TCXLPW-54		100 psiNPT1/8"54"Stainless Steel0.125"BrassViton€58.04

Working Mechanism

  • When the attached compressor attains the unload (cut-out) pressure, the pilot valve installed with these throttle controls sends a pneumatic signal to the air throttle control for actuating & extending to decrease the engine speed.
  • When the compressed air is used & the compressor obtains the load (cut-in) pressure, the pneumatic signal from the pilot valve retracts the throttle control to let the engine go back to its normal operating speed.

Features

  • Conrader air throttle controls are available in cable & airline styles.
  • Conrader cable-style throttle controls are installed on the pilot valve or other locations on the compressor while their cable end is attached to the engine throttle arm.
  • They have brass construction with stainless steel springs, Viton seals & a stainless steel cable that is permanently lubricated & self-cleaning.
  • Users should use routing clamps to securely mount the cable.
  • Conrader airline-style throttle controls are installed on the engine and attached to its throttle. The control's airline tube is positioned between the pilot valve & the throttle control.
  • They have brass construction with stainless steel springs, Viton seals, a stainless steel wire rod & plated steel brackets.
  • Selected models act as Honda air compressor throttle controls to regulate speeds of 5.5 to 13 hp Honda engines. Conrador TCXLIW-CH440 throttle control is suitable for use in 14 hp Kohler engines.
  • Conrador TCSA-5565S-SC throttle control is suitable for use in Honda GX390 engine. This Honda GX390 throttle control has a stroke length of 0.40 inches.

Frequently Asked Questions

What is the operating temperature of these Conrader throttle controls?

These Conrader air throttle controls operate at temperatures ranging from -15 to 400 degrees F.

What type of connections are available in these Conrader throttle controls?

Most of these Conrader air throttle controls have a 1/8 inch male NPT inlet connection and a 1/4 inch compression tube outlet connection.

What is the pressure rating of these Conrader throttle controls?

These Conrader air compressor throttle controls for petrol (gasoline) & diesel engines can operate at a maximum pressure of 500 psi.
