APPLETON ELECTRIC Explosionproof Junction Box
Appleton Electric explosion-proof junction boxes are ideal for a safe & reliable electrical connection, protecting against the risk of explosions and maintaining electrical integrity in hazardous locations. These Appleton explosion proof boxes are used in the oil & gas, chemical, pharma...ceutical and manufacturing industries.Read more
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O| Style | Model | Product Series | Hub Size | Composition | Cover Design | Approvals | Series | Nominal Width | Nominal Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | ACSEW206008 | - | - | - | - | - | - | - | - | €36,449.11 | |
| B | ASH250 | - | - | - | - | - | - | - | - | €57.64 | |
| C | ASH150 | - | - | - | - | - | - | - | - | €35.36 | |
| D | ASH125 | - | - | - | - | - | - | - | - | €28.53 | |
| E | ASH450 | - | - | - | - | - | - | - | - | €211.46 | |
| F | ASH350 | - | - | - | - | - | - | - | - | €106.52 | |
| G | AENGRAVE2 | - | - | - | - | - | - | - | - | €328.75 | |
| H | ASH200 | - | - | - | - | - | - | - | - | €41.30 | |
| I | ASH300 | - | - | - | - | - | - | - | - | €70.77 | |
| J | ASH600 | - | - | - | - | - | - | - | - | €296.76 | |
| K | ASH500 | - | - | - | - | - | - | - | - | €247.56 | |
| L | AENGRAVE1 | - | - | - | - | - | - | - | - | €197.29 | |
| M | AJBEW121208 | AE | 3 1/2" | Metallic | Lift-Off Cover | - | - | - | - | €4,367.12 | |
| M | AJBEW091105 | AE | 2" | Metallic | Lift-Off Cover | - | - | - | - | €2,563.81 | |
| M | AJBEW112005 | AE | 3" | Metallic | Lift-Off Cover | - | - | - | - | €3,953.93 | |
| M | AJBEW113006 | AE | 3" | Metallic | Lift-Off Cover | - | - | - | - | €6,543.34 | |
| M | AJBEW181808 | AE | 4" | Metallic | Lift-Off Cover | - | - | - | - | €8,966.16 | |
| N | AJBEW121206 | AE | - | Metallic | Lift-Off Cover | - | - | - | - | €5,076.45 | |
| M | AJBEW061604 | AE | 1 1/2" | Metallic | Lift-Off Cover | - | - | - | - | €2,351.18 | |
| M | AJBEW184207 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 24" | 48" | €15,365.78 | |
| M | AJBEW183008 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 23" | 35" | €13,622.76 | |
| M | AJBEW162408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 28" | €12,270.56 | |
| M | AJBEW182410 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 24" | 30" | €12,824.90 | |
| O | AJBEW206008 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 25" | 65" | €36,088.22 | |
| M | AJBEW183608 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 24" | 42" | €15,008.23 | |
| M | AJBEW243610 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 31" | 43" | €25,140.30 | |
| O | AJBEW243008 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 29" | 35" | €17,271.82 | |
| M | AJBEW183610 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 24" | 42" | €17,497.85 | |
| M | AJBEW242410 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 29" | 29" | €16,027.46 | |
| M | AJBEW243608 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 31" | 43" | €22,731.54 | |
| M | AJBEW303816 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 36" | 44" | €40,137.72 | |
| M | AJBEW161812 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 23" | €12,351.43 | |
| M | AJBEW303808 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 36" | 44" | €31,613.76 | |
| M | AJBEW242408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 29" | 29" | €13,895.36 | |
| M | AJBEW182408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 24" | 30" | €12,380.83 | |
| O | AJBEW162806 | AJBEW Series | 3" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 33" | €11,805.48 | |
| M | AJBEW101406 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 15" | 19" | €3,489.24 | |
| M | AJBEW061204 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 11" | 16" | €2,023.06 | |
| M | AJBEW060804 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 10" | 12" | €1,291.78 | |
| M | AJBEW061004 | AJBEW Series | 1 1/2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 11" | 15" | €1,456.37 | |
| M | AJBEW071106 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 12" | 16" | €2,386.30 | |
| M | AJBEW081006 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 13" | 15" | €2,483.20 | |
| M | AJBEW080806 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 12" | 12" | €2,309.83 | |
| M | AJBEW101006 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 15" | 15" | €2,972.68 | |
| M | AJBEW091504 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 14" | 20" | €2,905.53 | |
| M | AJBEW101408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 15" | 19" | €3,989.58 | |
| M | AJBEW081307 | AJBEW Series | 2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 13" | 17" | €3,117.27 | |
| M | AJBEW181806 | AJBEW Series | 3 1/2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 23" | 23" | €6,469.80 | |
| M | AJBEW112406 | AJBEW Series | 3" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 16" | 29" | €6,062.49 | |
| M | AJBEW121806 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 17" | 23" | €4,732.05 | |
| M | AJBEW153707 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 43" | €12,665.15 | |
| M | AJBEW142408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 20" | 29" | €10,469.32 | |
| O | AJBEW162206 | AJBEW Series | 3" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 22" | 27" | €7,213.62 | |
| M | AJBEW161606 | AJBEW Series | 3 1/2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 21" | €5,760.54 | |
| M | AJBEW121808 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 17" | 23" | €6,455.09 | |
| M | AJBEW141408 | AJBEW Series | 3" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 19" | 19" | €5,866.93 | |
| M | AJBEW122408 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 17" | 29" | €7,646.13 | |
| M | AJBEW141406 | AJBEW Series | 3 1/2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 19" | 19" | €4,689.14 | |
| M | AJBEW161608 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 21" | 21" | €6,623.14 | |
| M | AJBEW133806 | AJBEW Series | 3 1/2" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 18" | 43" | €11,939.72 | |
| O | AJBEW123608 | AJBEW Series | 4" | Metallic | Hinged | csa.png, ul.png | Ajbew Series | 17" | 41" | €12,642.53 |
Features
- These Appleton explosion proof junction boxes offer an external flange to maximise internal space & enable efficient utilisation of the internal layout.
- They are equipped with bolt-on stainless steel slotted mounting feet for easy installation in both horizontal and vertical orientations.
- These explosion proof boxes have an O-ring gasket to ensure watertight integrity, providing safety and protection against hazardous environments.
- They have stainless steel cover bolts and hinges to enhance safety and durability.
- These Appleton explosion proof enclosures have a wide range of tapped and drilled outlets, offering flexibility & compatibility with various electrical configurations.
Compatible Accessories
- Appleton Electric AH0F12SS Hinge Kit: This hinge kit provides a convenient and secure solution for attaching doors to explosion-proof junction boxes, facilitating easy access to internal components while maintaining the integrity of the explosion-proof enclosure.
Standards and Approvals
- UL
- CSA
Frequently Asked Questions
What are the components included in these Appleton Electric explosion-proof junction boxes?
Major components include an enclosure, cover, sealing mechanism, mounting feet, drilled and tapped outlets and a ground lug package.
How to install these Appleton explosion proof junction boxes?
- Select a suitable location complying with hazardous area classification and installation requirements.
- Prepare the mounting surface, ensuring cleanliness and levelness.
- Make electrical connections following the wiring diagram and guidelines provided.
- Install the sealing mechanism, such as the O-ring gasket and secure the cover tightly using the specified bolts or fasteners.
- Ensure proper grounding by utilising the provided ground lug package.
- Test and inspect connections, sealing and functionality for compliance and integrity.
What are the factors to consider while choosing Appleton explosionproof junction boxes?
Major factors include hazardous location classification, material, size, certifications, temperature rating, IP rating, cable entries, mounting options, accessibility, compatibility and environmental conditions.
