GENERAL ELECTRIC Thermal Units

Used in motor starters to ensure motor life extension by preventing thermal overheating conditions. Deliver full-load current ratings ranging between 0.43 and 27.7 A

Filter

GENERAL ELECTRIC -

Thermal Unit

A

B

C

D

E

F

G

H

I

Style	Model	FL Amp @ 3-Ph/ Size 3/ Open & Large Enclosure	FL Amp @ 1-Ph/ Size 00,0,1/ Open & Large Enclosure	FL Amp @ 1-Ph/ Size 00,0,1/ Standard Enclosure	FL Amp @ 3-Ph/ Size 3/ Standard Enclosure	FL Amp @ 3-Ph/ Size 4/ Open & Large Enclosure	FL Amp @ 3-Ph/ Size 4/ Standard Enclosure	FL Amp @ 3-Ph/ Size 5/ Standard Enclosure	Full Load Amps	Price (ex. VAT)
A	CR123C104B	-	10.50	9.60 to 10.7	-	-	-	185 to 200	9.19 to 10.50	€23.65
B	CR123H188A	-	-	-	-	-	-	-	1.63	€26.59
C	CR123H099A	-	-	-	-	-	-	-	0.86	€26.59
C	CR123H082A	-	-	-	-	-	-	-	0.71	€26.59
D	CR123F149C	-	-	-	-	131	122	-	122.00 to 131.00	€24.35
E	CR123C955A	-	9.50	9.12 to 9.59	-	-	-	169 to 184	8.47 to 9.92	€23.65
E	CR123C778A	-	7.71	7.12 to 7.92	-	-	-	139 to 155	6.92 to 7.72	€23.65
E	CR123C630A	-	6.39	6.16 to 6.62	-	-	-	119 to 128	5.72 to 6.39	€23.65
F	CR123C440B	-	-	-	-	-	-	-	40.60 to 43.20	€23.65
G	CR123C071A	-	0.65	0.62 to 0.65	-	-	-	-	0.58 to 0.65	€23.65
H	CR123C060A	-	0.55	0.52 to 0.55	-	-	-	-	0.48 to 0.55	€23.65
B	CR123H186B	-	-	-	-	-	-	-	16.00	€26.59
B	CR123H132B	-	-	-	-	-	-	-	11.40	€26.59
C	CR123H132A	-	-	-	-	-	-	-	1.14	€26.59
C	CR123H112B	-	-	-	-	-	-	-	9.75	€26.59
C	CR123H067A	-	-	-	-	-	-	-	0.58	€26.59
C	CR123H061A	-	-	-	-	-	-	-	0.53	€26.59
G	CR123C109A	-	1.03	0.98 to 1.05	-	-	-	-	0.92 to 1.03	€23.65
E	CR123C867A	-	8.72	7.93 to 9.11	-	-	-	156 to 168	7.91 to 8.96	€23.65
E	CR123C419A	-	4.43	3.97 to 4.60	-	-	-	-	4.03 to 4.43	€23.65
I	CR123C356A	-	3.57	3.20 to 3.67	-	-	-	-	3.25 to 3.57	€23.65
G	CR123C268A	-	2.43	2.27 to 2.55	-	-	-	-	2.24 to 2.43	€23.65
B	CR123H122B	-	-	-	-	-	-	-	10.60	€26.59
B	CR123H157B	-	-	-	-	-	-	-	13.60	€26.59
G	CR123C148A	-	1.40	1.25 to 1.35	-	-	-	-	1.23 to 1.40	€23.65
