ASHCROFT Pressure And Vacuum Switches

Diaphragm pressure switches suitable for supervising pressurised fluids in pumps, compressors and HVAC equipment. Selected models feature watertight and explosion-proof enclosures and a Viton actuator seal for handling burst pressures up to 18000 psi

Filter

ASHCROFT -

Diaphragm Pressure Switch

A

B

Style	Model	Max. Pressure	Min. Differential Pressure	Max. Differential Pressure	Range	Min. Pressure	Overall Width	Overall Height	Overall Depth	Price
A	LPAN4HV25XCYLM15	15 psi	2.5 psi	13 psi	1.5 psi to 15 psi	1.5 psi	4/25"	0.19"	0.24"	€610.27
A	LPDN4GGV25XCYLM15	15 psi	1.4 psi	2.1 psi	1.5 psi to 15 psi	1.5 psi	4/25"	0.19"	0.24"	€610.27
B	B424VXCYLM15	15 psi	0.5 psi	1.5 psi	1.5 psi to 15 psi	1.5 psi	4"	5.11"	3.31"	€375.93
A	LPDN4GGV25XCYLM30	30 psi	1.4 psi	5 psi	3 psi to 30 psi	3 psi	4/25"	0.19"	0.24"	€637.29
A	LPAN4HV25XCYLM30	30 psi	3 psi	27 psi	3 psi to 30 psi	3 psi	4/25"	0.19"	0.24"	€610.27
B	B424VXCYLM30	30 psi	0.5 psi	1.5 psi	3 psi to 30 psi	3 psi	4"	5.11"	3.31"	€399.59
A	LPDN4GGV25XCYLM60	60 psi	3 psi	7 psi	6 psi to 60 psi	6 psi	4/25"	0.19"	0.24"	€610.33
A	LPAN4HV25XCYLM60	60 psi	5 psi	54 psi	6 psi to 60 psi	6 psi	4/25"	0.19"	0.24"	€610.27
B	B424VXCYLM60	60 psi	1 psi	3.5 psi	6 psi to 60 psi	6 psi	4"	5.11"	3.31"	€375.93
B	B424VXCYLM100	100 psi	1.5 psi	5 psi	10 psi to 100 psi	10 psi	4"	5.11"	3.31"	€375.93
A	LPAN4HV25XCYLM100	100 psi	10 psi	90 psi	10 psi to 100 psi	10 psi	4/25"	0.19"	0.24"	€610.27
A	LPDN4GGV25XCYLM100	100 psi	7 psi	12 psi	10 psi to 100 psi	10 psi	4/25"	0.19"	0.24"	€637.29
A	LPAN4HV25XCYLM200	200 psi	18 psi	180 psi	20 psi to 200 psi	20 psi	4/25"	0.19"	0.24"	€610.27
B	B424VXCYLM200	200 psi	5 psi	13 psi	20 psi to 200 psi	20 psi	4"	5.11"	3.31"	€375.93
A	LPDN4GGV25XCYLM200	200 psi	10 psi	23 psi	20 psi to 200 psi	20 psi	4/25"	0.19"	0.24"	€649.91
B	B424VXCYLM400	400 psi	5 psi	24 psi	40 psi to 400 psi	40 psi	4"	5.11"	3.31"	€444.84
A	LPAN4HV25XCYLM400	400 psi	45 psi	360 psi	40 psi to 400 psi	40 psi	4/25"	0.19"	0.24"	€610.27
A	LPDN4GGV25XCYLM400	400 psi	22 psi	42 psi	40 psi to 400 psi	40 psi	4.12"	4.72"	6.09"	€610.27
B	B424VXCYLM600	600 psi	9 psi	30 psi	60 psi to 600 psi	60 psi	4"	5.11"	3.31"	€375.93
B	B424BXCYLM1000	1000 psi	30 psi	110 psi	100 psi to 1000 psi	10 psi	4"	5.11"	3.31"	€454.27
B	B424BXCYLM3000	3000 psi	80 psi	235 psi	300 psi to 3000 psi	300 psi	4"	5.11"	3.31"	€454.27
