VAL-MATIC Air And Vacuum Release Valves

Val-Matic air / vacuum release valves feature non-clog design and are ideal for releasing large quantities of air / vacuum from the system. They have a high / low-pressure resilient seating and an inflow preventer on the outlet to prevent fluid contamination.

Filter

VAL-MATIC -

Air Vacuum Valves

VAL-MATIC 101STK

A

Style	Model	Inlet Size	Outlet Size	Connection Type	Body Material	Vacuum Pressure	Min. Pressure	Max. Pressure	Grade	Price
A	101STK	1"	1"	FNPT	Cast Iron	29 in. hg	5 psi	300 psi	Grade 316	€946.90
A	100STK	1/2"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	300 psi	Grade 316	€830.07
A	102STK	2"	2"	FNPT	Cast Iron	29 in. hg	5 psi	300 psi	Grade 316	€1,524.71
A	103STK	3"	3"	FNPT	Cast Iron	29 in. hg	5 psi	300 psi	Grade 316	€2,455.34

VAL-MATIC -

Air Release/Air Vacuum Valves

A

VAL-MATIC 201C.2

B

Style	Model	Max. Pressure	Inlet Size	Outlet Size	Connection Type	Body Material	Vacuum Pressure	Min. Pressure	Grade	Price
A	803A	150 psi	3"	3"	FNPT	Cast Iron	29 in. hg	20 psi	Grade 316	€4,962.15
A	801A	150 psi	2"	1"	FNPT	Cast Iron	29 in. hg	-	Grade 316	€2,591.65
A	802A	150 psi	2"	2"	FNPT	Cast Iron	29 in. hg	20 psi	Grade 316	€3,856.44
B	201C.2	300 psi	-	1"	FNPT	Cast Iron	29 in. hg	-	Grade 316	€996.98
B	204C.2	300 psi	4"	-	FNPT	Cast Iron	29 in. hg	20 psi	Grade 316	€4,219.95
B	203C.2	300 psi	3"	3"	FNPT	Cast Iron	29 in. hg	20 psi	Grade 316	€3,177.85
B	202C.2	300 psi	2"	2"	FNPT	Cast Iron	29 in. hg	-	Grade 316	€1,515.94

VAL-MATIC -

Air Release Valves
Val-Matic air release valves are designed for use in pipelines, handling solid-laden fluids, for continually releasing unwanted air and feature 316 stainless steel internal components for withstanding exposure to hydrogen sulfide & aggressive fluids. These units come equipped with a hexagonal stem in round bushing guided floats for preventing the accumulation of debris and a non-clog design for minimising the need for backwashing. Choose from a wide variety of these NSF 61 & 372 certified valves, available in 150 & 175 psi maximum pressures on Raptor Supplies.

A

B

VAL-MATIC 15A.3

C

D

VAL-MATIC 15A.2

E

Style	Model	Max. Pressure	Inlet Size	Outlet Size	Connection Type	Body Material	Vacuum Pressure	Min. Pressure	Grade	Price
A	48A	150 psi	2"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€1,486.70
B	38.2	150 psi	2"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€824.23
B	38	150 psi	1"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€727.74
A	48A.2	150 psi	3"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€1,644.41
A	48A.3	150 psi	4"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€1,997.11
C	15A.3	175 psi	1"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€276.37
D	15A	175 psi	1/2"	1/2"	FNPT	Cast Iron	29 in. hg	5 psi	Grade 316	€248.50
E	15A.2	175 psi	-	1/2"	FNPT	-	-	-	Grade 316	€262.11

VAL-MATIC -

Air Release Valve With Hood, 300 Psi

Air Release Valve With Hood, 300 Psi

Model	Item	Price (ex. VAT)
SPK-5H/25.6H	ED4FAD	€544.50
