ZURN 2-850TUXL Water Pressure Reducing Valves, 2 Inch Pipe, 400 psi, Up to 350 Deg F, Female NPT
Item: CV4JWZModel: 2-850TUXLCross Ref: 801HF0
7 In Stock
Ships within 2 days via
10.00% off
€1,033.04 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Valve |
| 3-a Compliance | Not Rated |
| Ball Material | Bronze |
| Ball Port Style | Full Port |
| Body Material | Bronze |
| Coefficient Of Volume (cv) | Not Rated |
| Connection Gender - Side 1 | Female |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 2" |
| Connection Size - Side 2 | 2" |
| Connection Type | FNPT |
| Connection Type - Side 1 | NPT |
| Connection Type - Side 2 | NPT |
| For Media | Air, Combustible Gases, Steam, Water |
| Handle | Lever |
| Handle Color | Green |
| Handle Height | 3.88" |
| Handle Length | 4 3/4" |
| Handle Material | Stainless Steel |
| Max. Pressure | 400 psi |
| Max. Pressure (combustible Gas) | Not Rated |
| Max. Pressure (cwp) | 400 psi |
| Max. Pressure (steam) | 400 psi |
| Media Temperature Range | 33°F to 350°F |
| Nominal Valve Size | 2" |
| Overall Length | 4 1/2" |
| Pipe Size | 2" |
| Seat Material | Tfe |
| Stem Material | Brass |
| Temp. Range | 0°F to +350°F |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Straight |
| Valve Construction | One-Piece |
| Valve Series | 850XL Series |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 2.93 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 11.43 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Overall Length | Pipe Size | Body Material | Connection Type | Max. Pressure | Ball Material | Seat Material | Stem Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
12-850XL | - | - | - | - | - | - | - | - | €116.78 | |
 |
112-850TXL | 3 3/4" | 1 1/2" | Bronze | FNPT | 400 psi | Bronze | Tfe | Brass | €403.06 | |
 |
2-850XL | 4 1/2" | 2" | Bronze | FNPT | 400 psi | Bronze | Tfe | Brass | €575.60 | |
 |
112-850UXL | 3 3/4" | 1 1/2" | Bronze | FNPT | 400 psi | Bronze | Tfe | Brass | €803.14 | |
 |
112-850TUXL | 3 3/4" | 1 1/2" | Bronze | FNPT | 400 psi | Bronze | Tfe | Brass | €856.98 |
