WINTERS INSTRUMENTS PETW213LF Water Test Gauge 2.5 inch 0 to 160 psi
Item: AG9HHCModel: PETW213LFCross Ref: 20JN42
7 In Stock
Ships within 2 days via
10.00% off
€28.56 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pressure Gauge |
| Accuracy | +/-3-2-3% |
| Accuracy Grade | ASME B40.100 Grade B |
| Accuracy Scale | Mid Scale |
| Ambient Operating Temperature Range | 32°F to 150°F |
| Application | Commercial, Residential |
| Basic Gauge Case Material | Steel |
| Calibration Certificate | No |
| Calibration Certificate Included | No |
| Case Color | Black |
| Case Depth | 0.97" |
| Case Diameter | 2.447" |
| Case Finish | Painted |
| Case Material | Steel |
| Cleaned For Oxygen Service | No |
| Compatible Process Media | Air, Natural Gas, Potable Water, Water |
| Connection Location | Top |
| Connection Size | 3/4" |
| Dial Color | White |
| Dial Face Material | Aluminum |
| Dial Size | 2 1/2" |
| Field Fillable | No |
| Freeze Resistant Movement | No |
| Gauge Case Material | Steel |
| Gauge Connection Location | Top |
| Gauge Connection Size | 3/4" |
| Gauge Panel Mountable | No |
| Gauge Primary Range Units | Psi |
| Hazardous Location Rating | Not Rated |
| Includes Calibration Certificate | No |
| Includes Mounting Hardware | No |
| Includes Vent Plug | No |
| Ip/nema Rating | NEMA IP52 |
| Lens Material | Acrylic |
| Liquid Filled | No |
| Liquid-filled Case | No |
| Manufacturer Warranty Length | 5 yrs. |
| Movement Material | Lead Free Brass |
| Nominal Dial Size | 2 1/2" |
| Nsf Certified | Yes |
| Pointer Material | Aluminum |
| Pressure And Vacuum Gauge Type | Pressure Gauge |
| Pressure Gauge Type | Potable Water Line Pressure Test Gauge |
| Pressure Range | 0 psi to 160 psi |
| Pressure Range Type | Pressure |
| Primary Application | Home Water Pressure Testing |
| Primary Pressure Range | 0 to 160 |
| Primary Scale Units | Psi |
| Process Connection | 3/4" FGHT Female |
| Process Connection Gender | Female |
| Process Connection Location | Top |
| Process Connection Size | 3/4" |
| Process Connection Type | FGHT |
| Process Temperature Range | -40°F to +150°F |
| Range | 0 psi to 160 psi |
| Removable Bezel | No |
| Scale Type | Dual |
| Secondary Pressure Range | 0 to 1100 |
| Secondary Scale Units | Kpa |
| Sensor Material | Phosphor Bronze |
| Sensor Type | Bourdon Tube |
| Series | PET-LF Series |
| Socket Material | Lead Free Brass |
| Wetted Parts Material | Lead Free Brass, Phosphor Bronze |
Shipping Info:
| Ship weight (kg) | 0.16 |
| Ship height (cm) | 2.46 |
| Ship length (cm) | 6.22 |
| Ship width (cm) | 6.22 |
| Country of Origin | CN |
Product Details:
- Pressure and Vacuum Gauge Type : Pressure Gauge
- Gauge Panel Mountable : No
- Liquid Filled : No
Product Variants
| Product | Model | Pressure Range | Secondary Pressure Range | Range | Primary Pressure Range | Pressure Range Type | Process Connection Location | Nominal Dial Size | Application | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
PETW217LF | 0 psi to 300 psi | 0 to 2100 | 0 psi to 300 psi | 0 psi to 300 psi | Pressure | Top | 2 1/2" | Commercial, Residential | €31.74 |
