WILKERSON M28-03-BK00B Standard Compressed Air Filter, 150 Psi Max. Incoming Pressure
Item: CH6QBHModel: M28-03-BK00BCross Ref: 55CR47
7 In Stock
Ships within 2 days via
10.00% off
€154.04 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Compressed Air Filter |
| Air Inlet Size | 3/8" |
| Air Inlet Type | NPT |
| Air Outlet Size | 3/8" |
| Air Outlet Type | NPT |
| Body Material | Aluminum |
| Bowl Material | Plastic |
| Bowl Size | 3 oz. |
| Connection Size | 3/8" |
| Connection Style | Air Line |
| Drain Included | Yes |
| Drain Port Size | 3/16" |
| Drain Port Size | 0.188" |
| Drain Type | Manual |
| Element Material | Borosilicate Cloth |
| Filter Bowl Capacity | 2.87 oz. |
| Filter Bowl Guard Included | Yes |
| Filter Bowl Material | Plastic |
| Filter Element Material | Borosilicate Cloth |
| Filter Media | Borosilicate Cloth |
| Filter Rating | 0.5 µm |
| Filter Type | Coalescing |
| For Fluid Type | Oil, Water |
| For Removal Of | Aerosol, Mist, Oil Fog, Particles |
| For Substance Type | Oil Aerosols, Solid Particulate, Water |
| Gauge Included | No |
| Includes | Differential Pressure Indicator |
| Iso Class | Class 2, Class 3 |
| Max. Flow | 120 CFM |
| Max. Inlet Pressure | 150 psi |
| Max. Temp. | 125°F |
| Maximum Flow Rate | 72 CFM |
| Maximum Operating Pressure | 150 psi |
| Minimum Operating Temperature | -13°F |
| Modular Connection | Modular Connection |
| No. Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Overall Depth | 2 7/8" |
| Overall Height | 9 1/4" |
| Overall Width | 2 7/8" |
| Pressure Drop | 3 psig |
| Seal Material | Nitrile |
| Series | M28 Series |
| Size - Air Treatment | Standard |
| System Location | Air Line |
| Weight | 1.1 lbs. |
Shipping Info:
| Ship weight (kg) | 0.65 |
| Ship height (cm) | 23.5 |
| Ship length (cm) | 7.3 |
| Ship width (cm) | 7.3 |
| Country of Origin | US |
Product Variants
| Product | Model | Air Inlet Size | Bowl Material | Overall Height | Air Outlet Size | Drain Type | Filter Bowl Material | Iso Class | Connection Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
M28-04-CH00B | 1/2" | Metal | 9 1/4" | 1/2" | Automatic | Aluminum | Class 1 | - | €576.84 | |
 |
M28-04-BG00B | 1/2" | Plastic | 9" | 1/2" | Automatic | Plastic | Class 2, Class 3 | - | €519.26 | |
 |
M28-03-BL00B | 3/8" | Metal | 9 1/4" | 3/8" | Manual | Aluminum | Class 2, Class 3 | 3/8" | €180.81 | |
 |
M28-04-BK00B | 1/2" | Plastic | 9 1/4" | 1/2" | Manual | Plastic | Class 2, Class 3 | 1/2" | €171.89 | |
 |
M28-04-BL00B | 1/2" | Metal | 9 1/4" | 1/2" | Manual | Aluminum | Class 2, Class 3 | 1/2" | €183.26 | |
 |
M28-06-BK00B | 3/4" | Plastic | 9 1/4" | 3/4" | Manual | Plastic | Class 2, Class 3 | 3/4" | €173.41 | |
 |
M28-06-BL00B | 3/4" | Metal | 9 1/4" | 3/4" | Manual | Aluminum | Class 2, Class 3 | 3/4" | €183.32 |
