WEG 15571881 AC High-Performance Drive, Enclosed, 230 VAC, 1Hp With 3-Phase And 1-Phase Input, A Frame | CV6LAZ

WEG 15571881 AC High-Performance Drive, Enclosed, 230 VAC, 1Hp With 3-Phase And 1-Phase Input, A Frame

Item: CV6LAZModel: 15571881
Check Availability
In Stock

Get it by Wednesday, Jul 1

€561.60 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item AC Drive
Analog Input Signal Type Current/Voltage
Analog Output Signal Type Current/Voltage
Carrier Frequency 2.5-15 kHz
Connection Type RS-485
Connector Type Screw Terminal
Controller Type High Performance
Discrete Input Type Sinking, Sourcing
Discrete Output Type Relay
Display Numeric LCD
Dynamic Braking Standard Without braking
Efficiency Rating 97%
Enclosure Type Enclosed
For Use With 3-Phase induction and permanent magnet AC Motors
Frame Size A
Fuse Type User Supplied External Fuse
Hp By Input Phase 1 hp
Input Amps Signal 0-20/4-20 mA
Input Resolution 10 bits
Input Signal 4-20 mA
Input Signal Type Voltage or Potentiometer
Input Voltage Signal Range 0-10V DC
Internally Bypassed No
Ip Rating IP20
Load Amps 0.15/0.5A
Memory Card Not Included
Mounting Din Rail, Panel, Wall
Mounting Size 35 mm
No. Of Analog Input Channels 1
No. Of Analog Output Channels 1
No. Of Discrete Input Points 4
No. Of Discrete Output Points 2
No. Of Input Channels 1
No. Of Input Phase 1, 3
No. Of Non Isolated Analog Input Commons 1
No. Of Non-isolated Analog Output Commons 1
No. Of Non-isolated Discrete Input Commons 1
No. Of Non-isolated Discrete Output Commons 1
No. Of Output Channels 1
No. Of Output Phases 3
No. Of Points Per Analog Input Common 1
No. Of Points Per Analog Output Common 1
No. Of Points Per Discrete Input Common 1
No. Of Points Per Discrete Output Common 1
No. Of Terminal Pins 3
Nominal Discrete Input Voltage 24V DC
Nominal Discrete Output Voltage 240V AC/24V DC
Nominal Drive Input Voltage 230V AC
Nominal Drive Output Voltage 230V AC
Output Amps Signal 0-20/4-20 mA
Output Frequency 0.1-500 Hz
Output Resolution 10 bits
Output Type PWM
Output Voltage Signal Range 0-10V DC
Phase 1, 3
Port Speed(s) Up to 38.4K baud
Power Supply 200-240V
Product Datasheet weg-14938005.pdf
Rated Amps (hd) 4.3A
Reverse Capability Built-In
Sccr Rating 65 kA
Series CFW500 Series
Temp. -10°C to +50°C , 0°C to 50°C
Voltage Type AC

Shipping Info:

Ship weight (kg) 1.12
Country of OriginBR

Documentation:

Datasheet

Product Variants

ProductModelPhaseEnclosure TypeOutput TypePrice
WEG 15572689 AC High-Performance Drive, Enclosed, 230 VAC, 3Hp With 3-Phase Input, A Frame | CV6LBB 155726893EnclosedPWM€701.49
WEG 15575202 AC High-Performance Drive, Enclosed, 230 VAC, 5Hp With 3-Phase Input, B Frame | CV6LBK 155752023EnclosedPWM€1,025.64
WEG 15575716 AC High-Performance Drive, Enclosed, 230 VAC, 10Hp With 3-Phase Input, D Frame | CV6LBU 155757163EnclosedPWM€2,164.14
WEG 15577211 AC High-Performance Drive, Enclosed, 460 VAC, 25Hp With 3-Phase Input, E Frame | CV6LBZ 155772113EnclosedPWM€3,702.60
