WATTS 2 LF3004 0821935 Dielectric Union, 2 Inch Fitting Pipe Size, 250 PSI, Polysulfone, Female NPT x Female NPT
Item: AF8EDXModel: 2 LF3004Cross Ref: 25CC92 / 0821935
7 In Stock
Ships within 2 days via
5.00% off
€176.82 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Dielectric Union |
| Application | Non-Potable Water, Steam |
| Basic Fitting Shape | Union |
| Body Finish | Galvanized |
| Body Material | Malleable Iron |
| Cross Reference | 0821935 |
| Dielectric Union Lead Free Designation | Lead Free |
| Finish, Coating | Zinc Plated Galvanized |
| Fitting Side A Gender | Female |
| Fitting Side A Material | Malleable Iron |
| Fitting Side A Nominal Pipe Size | 2" |
| Fitting Side A Type | NPT |
| Fitting Side B Finish/coating | Zinc Plated Galvanized |
| Fitting Side B Gender | Female |
| Fitting Side B Material | Malleable Iron |
| Fitting Side B Nominal Pipe Size | 2" |
| Fitting Side B Type | NPT |
| Gasket Material | Buna N |
| Hex Size | 4 1/8" |
| Insulator Material | Polysulfone |
| Max. Operating Pressure | 250 psi |
| Max. Pressure | 250 psi |
| Max. Temp. | 180°F |
| Nut Material | Malleable Iron |
| Nut Material Finish | Galvanized Malleable Iron , Zinc Plated |
| Overall Length | 3 1/8" |
| Pipe Size | 2" |
| Specific Fitting Shape | Dielectric Union |
| Temp. | 33°F to 180°F |
Shipping Info:
| Ship weight (kg) | 2.09 |
| Ship height (cm) | 7.62 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 5.08 |
| HS code | 7307199030 |
| Country of Origin | US |
Product Details:
- Insulator Material (Polysulfone)
Product Variants
| Product | Model | Pipe Size | Adapter Material | Fitting Side A Material | Fitting Side A Nominal Pipe Size | Fitting Side B Material | Fitting Side B Nominal Pipe Size | Inlet Material | Inlet Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1/2 LF 3004-1/2 | 1/2" | - | Steel | 1/2" | Steel | 1/2" | - | - | €49.01 | |
|
3/4 LF 3004 3/4 | 3/4" | - | Steel | 3/4" | Steel | 3/4" | - | - | €55.91 | |
|
1 LF 3004-1 | 1" | - | Steel | 1" | Steel | 1" | - | - | €118.54 | |
 |
11/2 LF3004 | 1 1/2" | - | Malleable Iron | 1 1/2" | Malleable Iron | 1 1/2" | - | - | €93.82 | |
 |
LF3004 1 1/4 | - | Steel | - | - | - | - | Steel | 1 1/4" | €80.07 | |
 |
LF3004 1 1/2 | - | Malleable Iron | - | - | - | - | Malleable Iron | 1 1/2" | €121.69 | |
|
LF3004 1/2 | - | Steel | - | - | - | - | Steel | 1/2" | €40.02 |
