TSUBAKI 80LSA1RL Roller Link Sa-1 Attachment
Item: AB4KMVModel: 80LSA1RLCross Ref: 1YKR5
7 In Stock
Ships within 2 days via
10.00% off
€54.35 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Roller Chain Link |
| Ansi Chain Size | 80L |
| Attachment Number | SA-1 |
| Attachment Type | Tab |
| Centerline To Attachment End | 0.758" |
| Centerline To Hole Center | 16/25" |
| Chain Link Overall Width | 1.398" |
| Chain No. | 80 |
| Chain Overall Width | 1.398" |
| Chain Roller Dia. | 5/8" |
| Connecting End To Center Line | 0.758" |
| Extended Pin Diameter | 0.312" |
| Finish | Black Oxide |
| Industry Chain Pitch | 1" |
| Inside Pin Dia. | 0.312" |
| Link Type | Roller Attachment Link |
| Lubrication | Self Lubricating |
| Material | Steel |
| Max. Allowable Load | 3310 lbs. |
| Maximum Operating Temperature | 302°F |
| Minimum Operating Temperature | 14°F |
| Number Of Strands | 1 |
| Number Of Tab Holes | 1 |
| Outside Pin Dia. | 0.312" |
| Overall Width | 1.398" |
| Pin Contruction | Riveted Pin |
| Pin Length | 1.398" |
| Pin Link Plate Thickness | 1/8" |
| Pin Type | Riveted |
| Pitch | 1" |
| Plate Height | 0.949" |
| Plate Thickness | 5/8" |
| Rivet End To Center Line | 16/25" |
| Roller Chain Link Item | Roller Attachment Link |
| Roller Dia. | 5/8" |
| Roller Link Plate Height | 0.949" |
| Tensile Strength | 17600 lbs.-in. |
| Width Between Roller Link Plates | 5/8" |
Shipping Info:
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 3.55 |
| HS code | 7315190000 |
| Country of Origin | JP |
Product Variants
| Product | Model | Material | Ansi Chain Size | Finish | Roller Dia. | Pitch | Temp. Range | Tensile Strength | Inside Pin Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
80SA1RL | Steel | 80 | Plain | 5/8" | 1" | - | 15400 lbs.-in. | 0.312" | €27.38 | |
 |
80ASSA1RL | Stainless Steel | 80AS | Plain | 5/8" | 1" | -40°F to +750°F | - | 0.312" | €98.30 | |
 |
C2040LSA1RL | Steel | C2040L | Black Oxide | 0.312" | 1" | - | 3530 lbs.-in. | 0.156" | €23.47 | |
 |
C2040SA1RL | Steel | C2040 | Plain | 0.312" | 1" | +15°F to +300°F | 3750 lbs.-in. | 0.156" | €13.62 | |
 |
C2040ASSA1RL | Stainless Steel | C2040AS | Plain | 0.312" | 1" | -40°F to +750°F | - | 0.156" | €55.93 | |
|
C2042ASSA1RL | Stainless Steel | C2042AS | Plain | - | 1" | -40°F to +750°F | - | 0.156" | €70.70 | |
|
C2042LSA1RL | Steel | C2042L | Black Oxide | 5/8" | 1" | - | 3530 lbs.-in. | 0.156" | €33.56 |
