TECHNIKS 156500 Shrink Fit Tool Holder And Adapter, 1/2 Inch Shank Dia
Item: CU6DMJModel: 156500Cross Ref: 60AJ65
7 In Stock
Ships within 2 days via
10.00% off
€430.81 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Tool Holder |
| Balanced To Rpm | 25000 RPM |
| Balancing | G 2.5 @ 25000 RPM |
| Compatible Product Type | Shank Tools |
| Coolant Fed | Coolant Through |
| Features | Maximum T.I.R. Of 0.0001 In At 3X Diameter, Narrow Body Design For Better Clearance |
| For Use With | Hydraulic Tools |
| Hole Dia. | 1/2" |
| Mounting Length | 1.46" |
| Nose Dia. | 1.26" |
| Overall Length | 6.12" |
| Projection | 3.543" |
| Projection Length | 3.54" |
| Shank Dia. | 1/2" |
| Shank Diameter | 1.77" |
| Shank Type | Taper |
| Taper Size | BT40 |
Shipping Info:
| Ship weight (kg) | 1.31 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Shank Dia. | Projection | Taper Size | Balanced To Rpm | Nose Dia. | Hole Dia. | Tool Depth | End Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
22911 | - | 3" | Cat40 | - | 0.78" | - | - | Single End | €156.78 | |
|
22911-2.5 | - | 2 1/2" | Cat40 | - | 0.78" | - | - | Single End | €154.99 | |
|
22915 | - | 3" | Cat40 | - | 1" | - | - | Single End | €153.36 | |
 |
22915-2.5 | - | 2 1/2" | Cat40 | - | 1" | - | - | Single End | €171.54 | |
|
22917 | - | 3" | Cat40 | - | 1 1/4" | - | - | Single End | €156.78 | |
 |
22917-1.75 | - | 1 3/4" | Cat40 | - | 1 1/4" | - | - | Single End | €151.34 | |
|
22917-2.5 | - | 2 1/2" | Cat40 | - | - | - | - | Single End | €154.90 |
