TB WOODS SHBB QD Idler Bushing, Ductile Iron, SH Size, No Keyway, 1/2-13NC Stud Mounting
Item: CD6UDZModel: SHBBCross Ref: 806KT7
7 In Stock
Ships within 2 days via
10.00% off
€456.78 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Quick Detachable Bushing |
| Bearing Type | Radial Ball Bearing |
| Bolt Circle Dia. | 2 1/4" |
| Bolt Circle Diameter | 2.25" |
| Bolt Hole Diameter | 5/16" |
| Bore Bushing Series | SH |
| Bushing | Idler |
| Bushing Diameter | 1.87" |
| Bushing Material | Ductile Iron |
| Bushing Type | Quick Detachable |
| Coupling Size | SH |
| Dimension A | 0.38" |
| Dimension B | 1.871" |
| Dimension D | 2.69" |
| Dimension F | 1 1/4" |
| Dimension L | 1 1/4" |
| Dynamic Radial Load Capacity | 3320 lbf. |
| Flange Thickness | 0.38" |
| Flange Type | Solid |
| Hardware | Imperial Series |
| Idler Shaft Included | Yes |
| Idler Shaft Size | 1/2"-13 |
| Keyway | No Keyway |
| Material | Ductile Cast Iron |
| Maximum Speed | 5000 RPM |
| Maximum Temperature | 250°F |
| Mountable Length | 0.88" |
| Mounting Bolt Size | 1/4"-20 |
| Mounting Type | Stud |
| Number Of Bolt Holes | 3 |
| Outside Length | 3 1/8" |
| Overall Diameter | 2.69" |
| Overall Length | 3.13" |
| Set Screw Thread Size | 1/2"-13 |
| Size | SH |
| System Of Measurement | Imperial |
| Taper | 3/4 in./ft. |
| Type | Idler , QD Idler Bushing , Standard |
Shipping Info:
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 7.95 |
| Ship width (cm) | 2.54 |
Product Variants
| Model | Bolt Circle Dia. | Overall Length | Flange Thickness | Dimension B | Dimension A | Dimension F | Dimension D | Dimension L | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| SFBB1 | 3 7/8" | 5.25" | 1/2" | 3 1/8" | 1/2" | 1.38" | 4 5/8" | 2" | €856.35 | |
| SDBB | 2.688" | 3.88" | 0.44" | 2.188" | 11/25" | 18/25" | 3.19" | 1.81" | €583.66 | |
| SDBB58 | 2.688" | 3.88" | 0.44" | 2.188" | 11/25" | 1 1/4" | 3.19" | 1.81" | €583.66 | |
| SFBB | 3 7/8" | 4.5" | 1/2" | 3 1/8" | 1/2" | 1.38" | 4 5/8" | 2" | €856.35 | |
| SKBB | 3.313" | 4.5" | 1/2" | 2.813" | 1/2" | 1 1/4" | 3 22/25" | 1 22/25" | €666.92 |
