SQUARE D QOB220SWN Circuit Breaker Bolt On Qo 2pole 20a
Item: AF9GRDModel: QOB220SWNCross Ref: 2GNJ2
7 In Stock
Ships within 2 days via
5.00% off
€295.81 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Bolt On Circuit Breaker |
| Ac Voltage Rating | 120V AC |
| Ambient Rating | 104°F |
| Amps | 20A |
| Circuit Breaker Type | Switch Neutral , Switched Neutral |
| Dc Voltage | 48V DC |
| Depth | 2.9" , 2.91" |
| Electrical Connection | Pressure Plate |
| Frame Size | 100A/QO |
| Height | 3" |
| Interrupt Rating | 10 kA @ 120V AC |
| Length | 3" |
| Max. Air Rating | 10kA |
| Max. Air Rating | 10 kA |
| Min. Wire Size | 14 AWG |
| Mounting Type | Bolt On |
| No. Of Panel Spaces | 2 |
| No. Of Poles | 2 |
| Rating | Not Rated |
| Returnability | No |
| Terminal Connection | Screw Clamp |
| Terminal Connection Type | Screw Clamp |
| Tightening Torque | 35.4 lbf.-in. |
| Voltage | 120V AC |
| Width | 1.5" , 2 1/4" |
| Wire Size | 14 AWG to 8 AWG |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 9.65 |
| Ship width (cm) | 8.89 |
| HS code | 8536200020 |
| Country of Origin | MX |
Product Variants
| Product | Model | No. Of Poles | Amps | Voltage | Height | Depth | Electrical Connection | No. Of Panel Spaces | Returnability | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
QOB115CAFI | 1 | 15A | 120V AC | 4 4/5" | 2.91" | Pressure Plate | 1 | No | €260.08 | |
 |
QOB120CAFI | 1 | 20A | 120V AC | 4 4/5" | 2.91" | Pressure Plate | 1 | Yes | €260.08 | |
 |
QOB120VHCAFI | 1 | 20A | 120V AC | 4 4/5" | 2.91" | Pressure Plate | 1 | No | €505.96 | |
 |
QOB110 | 1 | 10A | 120/240V AC | 3" | 2.91" | Pressure Plate | 1 | Yes | €28.96 | |
 |
QOB115 | 1 | 15A | 120/240V AC | 3" | 2.91" | Pressure Plate | 1 | Yes | €28.07 | |
 |
QOB120 | 1 | 20A | 120/240V AC | 3" | 2.91" | Pressure Plate | 1 | Yes | €30.58 | |
 |
QOB130 | 1 | 30A | 120/240V AC | 3" | 2.91" | Pressure Plate | 1 | Yes | €31.57 |
