SQUARE D QO2100 Plug-In Circuit Breaker, 100 A, 10 kAIC at 240 V
Item: AA9GFQModel: QO2100Cross Ref: 1D251
7 In Stock
Ships within 2 days via
5.00% off
€108.74 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Plug In Circuit Breaker |
| Ac Voltage Rating | 120/240V AC |
| Air @ 120v Ac | 10 kA |
| Air @ 240v | 10 kA |
| Air @ 48v | 5 kA |
| Ambient Rating | 104°F |
| Amps | 100A |
| Circuit Breaker Actuator | Paddle |
| Circuit Breaker Mounting Style | Plug In |
| Circuit Breaker Type | Standard |
| Compatible Panelboard/load Center Series | Series QO |
| Dc Voltage | 48V , 48V DC |
| Depth | 2.9" , 2.91" |
| Electrical Connection | Box Lugs |
| For Use With | QO Load Centers And NQ Panelboards |
| Frame Size | 100A, QO |
| Height | 3 1/2" |
| Interrupt Rating | 10 kA @ 120/240V AC, 10 kA @ 120V AC |
| Length | 3 1/2" |
| Max. Air Rating | 10kA |
| Max. Air Rating | 10 kA At 120/240V AC |
| Max. Operating Temp. | 104°F |
| Max. Wire Size | 2 AWG |
| Min. Operating Temp. | 77°F |
| Min. Wire Size | 4 AWG |
| Mounting Type | Plug In |
| No. Of Panel Spaces | 2 |
| No. Of Poles | 2 |
| Phase | 1 |
| Product Datasheet | square-d-qo2100.pdf |
| Rating | HACR Rated |
| Returnability | Yes |
| Terminal Connection | Lug |
| Terminal Connection Type | Screw Clamp |
| Tightening Torque | 49.6 lbf.-in. |
| Voltage | 120/240V AC |
| Width | 1 1/2" , 1.5" |
| Wire Size | 2/0 AWG , 4 AWG to 2/0 AWG |
Shipping Info:
| Ship weight (kg) | 0.32 |
| Ship height (cm) | 8.38 |
| Ship length (cm) | 9.65 |
| Ship width (cm) | 4.06 |
| HS code | 8536200040 |
| Country of Origin | MX |
Product Details:
- Square D QO2100 is a 2-pole HACR-rated plug-in circuit breaker used in QO load centres, panelboards and switchboard distribution panels to provide protection against overloads and short-circuits. It accommodates copper or aluminium wires of sizes ranging from 4 to 2/0 AWG.
- This UL-listed and CSA-certified Square D circuit breaker works on current rating of 100 amperes, and 120 / 240 VAC and 48 VDC voltage ratings. It has a maximum current interrupting capacity of 10 kAIC.
- It comes equipped with the Visi-Trip indicator, which snaps the handle to a midpoint position (between OFF and ON) when the circuit breaker trips and indicates it with a red light.
Documentation:
Product Variants
| Product | Model | No. Of Poles | Amps | Voltage | Depth | No. Of Panel Spaces | Returnability | Height | Electrical Connection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
QO115 | 1 | 15A | 120/240V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €16.63 | |
 |
QO115HM | 1 | 15A | 120V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €33.73 | |
 |
QO120 | 1 | 20A | 120/240V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €16.63 | |
 |
QO120HM | 1 | 20A | 120V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €33.73 | |
 |
QO120VH | 1 | 20A | 120/240V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €43.81 | |
 |
QO130 | 1 | 30A | 120/240V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €17.18 | |
|
QO130VH | 1 | 30A | 120/240V AC | 2.91" | 1 | Yes | 3" | Pressure Plate | €43.81 |
