SQUARE D JGL37225D82 Molded Case Circuit Breaker, 225 A, 3 Pole, 600V AC
Item: EA6MPFModel: JGL37225D82Cross Ref: 6NHF9
7 In Stock
Ships within 2 days via
5.00% off
€5,404.23 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Circuit Breaker |
| Ac Voltage | 600V AC |
| Ac Voltage Rating | 600V AC |
| Ambient Air Temp. For Operation | -13°F to +158°F |
| Ambient Air Temp. For Storage | -58°F to +185°F |
| Amps | 225A |
| Application | HACR Rated Applications |
| Breaking Capacity Code | G |
| Circuit Breaker Mounting Style | Lug In/Lug Out |
| Circuit Breaker Type | Standard |
| Continuous Amps | 80% |
| Dc Voltage | 500V DC |
| Depth | 3 2/5" |
| Discount Schedule | 0DE2 |
| Electrical Connection | Lugs, Line, Load |
| For Use With | Free Standing |
| Frame Size | 250a/J |
| Height | 7 1/2" |
| High Amp Trip Setting | 850A |
| Ics Rated Service Breaking Capacity | 65 kA 220/240V AC 50/60 Hz, 35 kA 380/440/415V AC 50/60 Hz, 18 kA 500/525V AC 50/60 Hz, 20 kA 250V DC, 20 kA 500V DC |
| Ip Degree Of Protection | Front Cover IP40 |
| Long Time Pick-up Adjustment Range | 1/4" to 1" |
| Low Amp Trip Setting | 500A |
| Magnetic Tripping Amps | 500/850A |
| Max. Air Rating | Not Rated |
| Max. Wire Size | 3/0 AWG |
| Min. Wire Size | 4 AWG |
| Mounting | Lug In, Lug Out |
| Mounting Mode | Unit Mount Lug |
| Mounting Support | Lug |
| No. Of Poles | 3 , 3P |
| No. Of Slots | 5 |
| Operating Altitude | Less Than 6561.68 ft. (2000m) Without Derating 5000m With Derating |
| Phase | 3 |
| Phase Connection | ABC |
| Pollution Degree | 3 IEC 60947-1 |
| Power Wire Stripping Length | 1" |
| Product Or Component Type | Circuit Breaker |
| Protection Type | Overload Protection, Short-Circuit Protection |
| Quality Labels | CE |
| Range | Powerpact |
| Series | JG Series |
| Suitability For Isolation | Yes |
| Terminal Connection | Box Lug |
| Terminal Identifier | Al250jd |
| Trip Type | Thermal Magnetic |
| Ui Rated Insulation Voltage | 750V |
| Uimp Rated Impulse Withstand Voltage | 8 kV |
| Width | 4.09" |
Shipping Info:
| Ship weight (kg) | 2.2 |
| Ship height (cm) | 14.99 |
| Ship length (cm) | 22.86 |
| Ship width (cm) | 18.8 |
| Country of Origin | US |
