SQUARE D HOM2200BB Plug In Circuit Breaker Hom 200 Amp 240vac 2p 10kaic@240v
Item: AG8PZBModel: HOM2200BB
7 In Stock
Ships within 2 days via
10.00% off
€564.32 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Plug In Circuit Breaker |
| Aic Rating | 10 kAIC @ 240V |
| Frame Type | Home |
| Number Of Poles | 2 |
| Product Datasheet | square-d-hom2200bb.pdf |
| Voltage | 240V |
| Voltage Type | AC |
Shipping Info:
| Ship weight (kg) | 1.38 |
| Ship height (cm) | 14.73 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 18.54 |
| Country of Origin | MX |
Product Details:
- Square D HOM2200BB is a Homeline miniature circuit breaker designed for use with Homeline load centres to prevent damage from overloading.
- This HACR-rated Square D circuit breaker features a box lug electrical connection and plug-in mounting style.
- This circuit breaker has max voltage rating of 240 VAC and short-circuit current rating of 10 KA.
- It accommodates 4 - 300 AWG aluminium and copper wires and has a maximum line rated current of 200 A.
Documentation:
Product Variants
| Product | Model | Number Of Poles | Amps | Ac Voltage Rating | Max. Air Rating | Depth | Dc Voltage | Terminal Connection Type | Terminal Connection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HOM115 | 1 | 15A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | - | Screw Clamp | €22.93 | |
 |
HOM115GFI | 1 | 15A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €161.43 | |
|
HOM120 | 1 | 20A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €21.49 | |
 |
HOM120GFI | 1 | 20A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €245.65 | |
|
HOM130 | 1 | 30A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Screw Clamp | Screw Clamp | €21.61 | |
 |
HOM140 | 1 | 40A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Lug | Lug | €34.98 | |
|
HOM150 | 1 | 50A | 120V AC | 10 kA At 120V AC | 2.98" | Not Rated | Lug | Lug | €31.78 |
