SQUARE D EDB14030EPDBA Miniature Circuit Breaker 277V 30A
Item: CU4FVXModel: EDB14030EPDBACross Ref: 48R041
7 In Stock
Ships within 2 days via
5.00% off
€2,162.35 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Miniature Circuit Breaker |
| Ambient Air Temp. For Operation | 104°F |
| Amps | 30A |
| Application | Hid Rated Applications, HACR Rated Applications |
| Awg Gauge | 14 AWG to 6 AWG, 12 AWG to 4 AWG |
| Breaking Capacity | 18 kA 277V AC, 18 kA 240V AC, 25 kA 120V AC, 18 kA 120/240V AC |
| Breaking Capacity Code | D |
| Circuit Breaker Application | HID Rated, HACR Rated |
| Circuit Breaker Mounting Style | Bolt-On |
| Comm Code Enhanced | 32241 |
| Depth | 4.05" |
| Device Composition | Alarm Switch |
| Device Short Name | Edb |
| Discount Schedule | 0DE2 |
| Earth-leakage Protection Class | Class B |
| Earth-leakage Sensitivity | 30 mA |
| Electrical Connection | Lugs Aluminium |
| Family Series | Square D Circuit Breakers, E-Frame Series |
| For Use With | NF Panelboard |
| Frame Size | D, E |
| Height | 6 16/25" |
| Holding Amps | 270A |
| Iec Standard | 60947-2 |
| Interrupt Rating | 18 kA at 277/240/120V AC, 25 kA at 120V AC |
| Kaic @ 120 Vac | 25 kAIC |
| Local Signalling | Trip Indicator |
| Max. Air Rating | 25 kA |
| Max. Operating Voltage | 277V AC |
| Max. Wire Size | 6 AWG, 4 AWG |
| Mfr. Series | EDB |
| Min. Wire Size | 12 AWG, 14 AWG |
| Module Type | E Frame |
| Mounting Mode | Bolt On |
| No. Of Poles | 1 |
| No. Of Spaces | 2 |
| Protect Type | Overload Short Circuit , Overload, Short Circuit |
| Protection Type | Overload, Short-Circuit |
| Returnability | Yes |
| Series | EDB Series |
| Terminal Connection | Lug |
| Tightening Torque | 30.09 lbf.in. @ 0.004 sq. in. to 0.02 sq. in. @ 14 AWG to 6 AWG |
| Trip Sensitivity | 30 mA |
| Trip Type | Thermal Magnetic |
| Trip Unit Rating | 875A |
| Trip Unit Technology | Thermal-Magnetic |
| Type | Thermal Magnetic, Equipment Protector |
| Width | 1.96" |
Shipping Info:
| Ship weight (kg) | 0.99 |
| Ship height (cm) | 16.87 |
| Ship length (cm) | 10.29 |
| Ship width (cm) | 4.98 |
| Country of Origin | MX |
