SQUARE D 9050JCK16V20 Timer Relay 10 Min 8 Pin 10a Dpdt 120v
Item: AG7CJMModel: 9050JCK16V20Cross Ref: 5B398
7 In Stock
Ships within 2 days via
5.00% off
€160.17 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Time Delay Relay |
| Adjustment Method | Not Adjustable |
| Adjustment Method | Rotary Knob |
| Amps | 10A |
| Base Type | Octal |
| Body Depth | 2.75" |
| Body Height | 2.34" |
| Body Width | 1.72" |
| Coil Rating | 2 VA |
| Coil Rating | 2VA |
| Coil Voltage | 120V AC |
| Compatible With Manufacturer Model Number | 8501NR51, 8501NR52 |
| Contact Composition | 2 NO + 2 NC |
| Contact Form | DPDT |
| Contact Material | Silver Nickel |
| Contact Rating (ac) | 10A @ 120/240V |
| Contact Rating (dc) | 10A @ 30V |
| Delay Function | On Delay |
| Depth | 4.09" |
| Electrical Connection | Socket |
| Electrical Connection Type | Pin |
| Environmental Protection | Sealed |
| For Use With | 8501NR51, 8501NR52 |
| Frequency | 50/60 Hz |
| Function | On Delay |
| Green Certification Or Other Recognition | RoHS.png |
| Height | 2 2/5" |
| Input Voltage | 110/120V DC |
| Max. Operating Temp. | 150.8°F |
| Max. Switching Voltage | 240V AC |
| Max. Time Setting | 10 min. |
| Min. Operating Temp. | -18.4°F |
| Min. Time Setting | 0.1 sec. |
| Mounting | Plug In |
| Mounting Type | Socket |
| No. Of Delay Functions | 1 |
| No. Of Pins | 8 |
| No. Of Pins/terminals | 8 |
| Operating Functions | 1 |
| Operational Ambient Temp. Range | -28°C to +66°C |
| Pins | 8 |
| Power Consumption | 2 VA |
| Relay Mounting Style | Socket |
| Resistive Contact Amp Rating | 10A |
| Returnability | Yes |
| Shape Of Pins | Tubular |
| Socket Code | A |
| Supply Voltage | 120V AC, 110V DC |
| Switch Function | DPDT |
| Timing Mode | On Delay |
| Timing Range | 0.1 min. to 10 min. |
| Width | 1.7" |
Shipping Info:
| Ship weight (kg) | 0.15 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 11.18 |
| Ship width (cm) | 6.6 |
| HS code | 8536490080 |
| Country of Origin | US |
Product Variants
| Model | Input Voltage | Contact Material | Depth | Supply Voltage | No. Of Pins | Min. Time Setting | Adjustment Method | Max. Time Setting | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 9050JCK24V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 11 | 1.2 sec. | Rotary Knob | 120 sec. | €198.95 | |
| 9050JCK37V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 8 | 0.3 sec. | Rotary Knob | 30 min. | €155.60 | |
| 9050JCK60V20 | 120V AC | Silver Nickel | 3.6" | 120V AC | 8 | 0.05 sec. | Dip Switch | 999 hrs. | €270.77 | |
| 9050JCK52V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 8 | 0.3 sec. | Rotary Knob | 30 sec. | €260.28 | |
| 9050JCK42V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 11 | 0.3 sec. | Rotary Knob | 30 sec. | €147.08 | |
| 9050JCK31V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 8 | 0.1 sec. | Rotary Knob | 10 sec. | €147.08 | |
| 9050JCK27V20 | 110/120V DC | Silver Nickel | 4.09" | 120V AC, 110V DC | 11 | 0.3 sec. | Rotary Knob | 30 min. | €187.21 |
