SMC VALVES SY3140-6LZ Valve
Item: AL3UUEModel: SY3140-6LZ
7 In Stock
Ships within 2 days via
€77.76 /unit
This product can only be shipped in multiples of 2Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solenoid Valve |
| Actuation | Piloted Solenoid |
| Body Material | Zinc |
| Bracket Type | Without Bracket |
| Flow Direction | 4-Way |
| Lead Wire Length | 300 mm |
| Manual Operation Type | Non-Locking Push |
| Max. Operating Pressure | 145 psi |
| No. Of Port | 5 |
| No. Of Positions | 2 |
| No. Of Solenoids | 1 |
| Operating Medium | Air |
| Operating Temp. | 14°F to 122°F |
| Overall Height | 53.5 mm |
| Overall Length | 76.8 mm |
| Overall Width | 22 mm |
| Piping Type | Base Mounted |
| Seal Material | Rubber |
| Series | SY Series |
| Solenoid Electrical Entry | L Plug |
| Solenoid Power Consumption | 0.35 W |
| Thread Standard | RC |
| Valve Function | Spool |
| Valve Series | SY3000 Series |
| Voltage Suppressor | With Light, Surge Voltage Suppressor |
Shipping Info:
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 5.08 |
Product Variants
| Product | Model | Voltage | Overall Height | Overall Width | Actuation | Type | Driving Type | Operating Temp. | Pressure Rating (mpa) | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SY100-61-3-05 | - | - | - | - | - | - | - | - | €25.72 | |
 |
SY3440-5LOU | - | - | - | - | - | - | - | - | €138.65 | |
 |
SY3140-5LOU | - | - | - | - | - | - | - | - | €80.61 | |
 |
SY3240-3LZ | - | - | - | - | - | - | - | - | €93.33 | |
 |
SY3140-3LZ | 110V AC | - | - | Single | Solenoid Valve | 0.15 To 0.7 | - | 0.15 MPa to 0.7 MPa | €77.76 | |
 |
SX3140-5LOZ | - | - | - | - | - | - | - | - | €85.23 | |
|
SX3140-5MNZD | - | - | - | - | - | - | - | - | €69.37 |
