SCHNEIDER ELECTRIC RE22R1DMR Time Delay Relay, DIN-Rail Mounted, 240VAC, 8 A, 6 Pins/Terminals, 0.05 sec to 300 hr
Item: CU2EDZModel: RE22R1DMRCross Ref: 55WM58
7 In Stock
Ships within 2 days via
10.00% off
€95.83 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Time Delay Relay |
| Ac Contact Rating | 8A @ 250V |
| Adjustment Method | Diagnostic Button, Rotary Dip Switch |
| Amps Rating | 8A |
| Base Shape | Square |
| Body Depth | 2.87" |
| Body Height | 3.54" |
| Body Width | 0.89" |
| Contact Form | SPDT |
| Current Rating | 8A |
| Dc Contact Rating | 8A @ 24V |
| Delay Function | Symmetrical Flashing |
| Electrical Connection | Screw Terminal |
| Electrical Connection Type | Screw |
| Electrical Operating Durability | 100000 |
| Environmental Protection | Sealed |
| Frequency | 50/60 Hz |
| Input Voltage | 24-240V AC/DC |
| Ip Rating | IP20, IP40, IP50 |
| Maximum Operating Temperature | 140°F |
| Maximum Time Setting | 300 hrs. |
| Mechanical Operating Durability | 10000000 |
| Min. Time Setting | 0.05 sec. |
| Minimum Operating Temperature | -4°F |
| Minimum Time Setting | 0.05 sec. |
| No. Of Pins | 6 |
| No. Of Pins - Relay | 6 |
| Number Of Delay Functions | 1 |
| Number Of Pins/terminals | 6 |
| Operating Time Accuracy | -0.5% to +0.5% |
| Overall Depth | 3.54" |
| Overall Height | 3.54" |
| Power Consumption | 3 VA |
| Relay Mounting Style | Din Rail |
| Sealing | Sealed |
| Timing Relay Functionality | Off Delay, On Delay |
Shipping Info:
| Ship weight (kg) | 0.09 |
| Ship height (cm) | 8.99 |
| Ship length (cm) | 7.29 |
| Ship width (cm) | 2.26 |
| Country of Origin | ID |
Product Variants
| Product | Model | Relay Mounting Style | Delay Function | Electrical Connection Type | Input Voltage | Amps Rating | Contact Form | Min. Time Setting | Socket Code | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TDR782XDXA-110A | Socket | On Delay | Pin | 110V AC | 5A | 4PDT | 0.1 sec. | G | - | RFQ
|
 |
TDR782XBXA-110A | Socket | On Delay | Pin | 110V AC | 5A | DPDT | 0.1 sec. | K | - | RFQ
|
 |
TDR782XBXA-12D | Socket | On Delay | Pin | 12V DC | 5A | DPDT | 0.1 sec. | Q | €84.51 | |
 |
TDR782XDXA-230A | Socket | On Delay | Pin | 230V AC | 5A | 4PDT | 0.1 sec. | G | - | RFQ
|
 |
TDR782XBXA-230A | Socket | On Delay | Pin | 230V AC | 5A | DPDT | 0.1 sec. | K | - | RFQ
|
 |
TDR782XDXA-24A | Socket | On Delay | Pin | 24V AC | 5A | 4PDT | 0.1 sec. | G | - | RFQ
|
 |
TDR782XBXA-24A | Socket | On Delay | Pin | 24V AC | 5A | DPDT | 0.1 sec. | K | - | RFQ
|
