RITTAL DK 7030000 Processing Units
Get it by Tuesday, Aug 25
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Processing Unit |
| Alarm Relay Output | Terminal up to 1.5 sq. mm (max. 24 V DC/1 A) |
| Ambient Humidity (non Condensing) | 5% to 95% |
| Applications | Enclosure Monitoring In It, Industry And Facility Management |
| Depth | 5 1/5" |
| Front Color | Ral 9005 |
| Front Surface Finish | Smooth |
| Function Principle | Central Monitoring Unit For The Cmc Iii System., Collects Measurement Data And Alerts Network Management Systems Or Control Rooms When Freely Adjustable Limit Values Are Exceeded., Automatic Monitoring Of Input And Control Of Remote Outputs. |
| Height | 1.57" |
| Housing Color | Ral 7035 |
| Housing Finish | Textured |
| Infrared Access Sensor | Yes |
| Integral Temperature Sensor | Yes |
| Interface Bus System | 2 x RJ45 CAN Bus |
| Interface Streaming | Axis Network Camera With Vapix Version 3 |
| Interface Ups | Terminal, Socket, Poe (Power Over Ethernet) |
| Interfaces | Mini USB, 1 X USB, Sd Storage Card Slot (Max. 32 Gb), 2 Digital Inputs |
| Led Displays (front) | Status |
| Led Displays (rear) | Network Status |
| Material | Plastic |
| Max. No. Of Sensors | 32 |
| Network Interface | Ethernet In Line With Ieee 802.3 Via 10/100 Baset Full-Duplex 10/100 Mbit/S, Poe |
| Operating Temp. Range | 0°C to 45°C |
| Protocols | Tcp/Ipv4, Tcp/Ipv6, Snmpv1, Snmpv2C, Snmpv3, Telnet, Ssh, Ftp, Sftp With Ssl, Http, Https With Ssl, Ntp, Dhcp, Dns, Smtp, Syslog, Ldap, Radius, Opc-Ua, Modbus/Tcp, Rs-232 |
| Serial Interface | Rj12 |
| Width | 5.43" |
Shipping Info:
| Ship weight (kg) | 0.63 |
| Ship height (cm) | 3.99 |
| Ship length (cm) | 13.21 |
| Ship width (cm) | 13.79 |
