RED HAT SC8356A002V Solenoid Valve 3/2 1/8 Inch NC 24/60V
Item: AH9UWWModel: SC8356A002VCross Ref: 44U336
7 In Stock
Ships within 2 days via
10.00% off
€97.64 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solenoid Valve |
| Body Material | Brass |
| Center Line Pipe Center Size | 1.812" |
| Class | Class F |
| Coefficient Of Volume | 0.09 |
| Coil Enclosure | Watertight No Junction Box |
| Coil Insulation Class | F |
| Electrical Connection | DIN |
| Environmental Protection | Indoor, Outdoor |
| For Media | Air, Hot Water, Inert Gases, Light Oil, Oxygen, Steam, Water |
| Hz | 60 Hz |
| Includes Coil | Yes |
| Ip Rating | IP65 |
| Max. Fluid Temp. | 180°F |
| Max. Operating Pressure Differential - Air/inert Gas | 145 psi |
| Max. Operating Pressure Differential - Light Oil | 145 psi |
| Max. Operating Pressure Differential - Steam | Not Rated |
| Max. Operating Pressure Differential - Water | 145 psi |
| Min. Operating Pressure Differential | 0 psi |
| Mounting Orientation | Horizontal, Vertical |
| Nema Rating | 4 |
| Nominal Pipe Size | 1/8" |
| Operating Environment | Indoor, Outdoor |
| Operation | Direct Acting |
| Operation Type | Direct Acting |
| Orifice Dia. | 0.062" |
| Orifice Diameter | 1/16" |
| Overall Height | 2 1/16" |
| Overall Length | 1 5/16" |
| Overall Width | 1" |
| Pipe Size | 1/8" |
| Type | Air, Inert Gas, Light Oil, Water |
| Valve Configuration | Normally Closed |
| Valve Positions | 2 Position |
| Valve Type | Compact |
| Valve Ways | 3-Way |
| Valve Ways And Positions | 3 Ways And 2 Positions |
| Wattage | 6.3 W |
Shipping Info:
| Ship weight (kg) | 0.16 |
| Ship height (cm) | 7.87 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
Product Details:
- Solenoid Valve Product Group : Solenoid Valve
- Max. Operating Pressure Differential Air/Inert Gas : 145 psi
- Max. Operating Pressure Differential Water : 145 psi
- Max. Operating Pressure Differential Light Oil : 145 psi
