RED HAT 8342G501 Single Solenoid Valve 4/2 1/4 Inch 120/110V
Item: AH9UVRModel: 8342G501Cross Ref: 44U303
7 In Stock
Ships within 2 days via
€484.01 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Solenoid Valve |
| Application | Analytical And Diagnostic Equipment, Biofuel And Heating Systems, Dust Collector Systems, Heating Equipment, Refining Applications |
| Body Material | Brass |
| Class | Class F |
| Coefficient Of Volume | 0.7 |
| Coil Enclosure | Watertight No Junction Box |
| Coil Insulation Class | F |
| Electrical Connections | 1/2" Conduit W/18" Leads |
| Environmental Protection | Indoor, Outdoor |
| For Media | Air, Inert Gases, Light Oil, Water |
| Frequency | 50/60 Hz , 60 Hz |
| Included Coil | Yes |
| Included Seals | Yes |
| Inlet Connection Type | NPTF |
| Ip Rating | IP66 |
| Max. Ambient Temp. | 125°F |
| Max. Fluid Temp. | 160°F |
| Max. Operating Pressure Differential Air/inert Gas | 125 psi |
| Max. Operating Pressure Differential Light Oil | Not Rated |
| Max. Operating Pressure Differential Steam | Not Rated |
| Max. Operating Pressure Differential Water | Not Rated |
| Min. Ambient Temp. | 32°F |
| Min. Operating Pressure Differential | 0 psi |
| Mounting Orientation | Horizontal, Vertical |
| Nema Rating | NEMA 1, NEMA 2, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X |
| Nominal Pipe Size | 1/4" |
| Operating Environment | Indoor, Outdoor |
| Operation | Direct Acting |
| Operation Type | Direct Acting |
| Orifice Dia. | 0.188" , 3/16" |
| Outlet Connection Type | NPTF |
| Overall Height | 4 3/8" |
| Overall Length | 2 15/32" |
| Overall Width | 1 15/16" |
| Pipe Size | 1/4" |
| Seal Material | PTFE |
| Type | Air, Inert Gas |
| Valve Configuration | Configurable |
| Valve Positions | 2 Position |
| Valve Type | Namur Mount |
| Valve Ways | 4-Way |
| Valve Ways And Positions | 4 Ways And 2 Positions |
| Voltage | 120V AC |
| Watts | 20.1 W |
Shipping Info:
| Ship weight (kg) | 1.28 |
| Ship height (cm) | 11.43 |
| Ship length (cm) | 5.72 |
| Ship width (cm) | 5.08 |
| Country of Origin | MX |
Product Details:
- Solenoid Valve Product Group : Solenoid Valve
- Max. Operating Pressure Differential Air/Inert Gas : 125 psi
- Max. Operating Pressure Differential Light Oil : Not Rated
