PIC GAUGES 701DDS-T-254C Molded Gauge And Seal Assembly Seal
Item: AF6KDHModel: 701DDS-T-254CCross Ref: 19RZ40
7 In Stock
Ships within 2 days via
10.00% off
€281.26 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Molded Gauge and Seal Assembly |
| Accuracy | +/-2-1-2% |
| Accuracy Grade | ASME B40.1 Grade A |
| Accuracy Scale | Mid Scale |
| Adjustable Pointer | No |
| Ambient Operating Temperature Range | -4°F to +140°F |
| Application | Water Treatment Applications |
| Basic Gauge Case Material | Plastic |
| Basic Gauge Sensor Material | Brass |
| Basic Gauge Socket Material | Plastic |
| Bezel Material | Polyvinylidene Fluoride |
| Blowout Safety Back | No |
| Calibration Certificate Included | No |
| Case Color | White |
| Case Construction | One Piece Molded |
| Case Depth | 1.61" |
| Case Dia. | 3 4/25" |
| Case Diameter | 3.16" |
| Case Finish | Pvdf |
| Case Material | Plastic |
| Cleaned For Oxygen Service | No |
| Clog Resistant | No |
| Connection Location | Lower |
| Dial Color | White |
| Diaphragm Seal Type | Threaded |
| Field Fillable | Yes |
| For Use With | Wastewater Treatment, Water |
| Freeze Resistant Movement | No |
| Gauge Case Color | White |
| Gauge Case Material | PVDF |
| Gauge Connection Location | Bottom |
| Gauge Connection Size | 1/4" |
| Gauge Nominal Dial Size | 2 1/2" |
| Gauge Panel Mountable | No |
| Gauge Primary Range No.ed Graduations | 10 |
| Gauge Primary Range Units | Psi |
| Graduations | 5 psi |
| Hazardous Location Rating | Not Rated |
| Includes | Vent Plug With Ptfe Seal |
| Includes Mounting Hardware | No |
| Includes Vent Plug | Yes |
| Ip/nema Rating | Nema Ip65 |
| Lens Material | Polycarbonate |
| Liquid Filled | No |
| Liquid-filled Case | No |
| Manufacturer Warranty Length | 1 yr. |
| Mounting Hardware Included | No |
| Mounting Type | Stem Mount |
| Nominal Dial Size | 2 1/2" |
| Panel-mountable | No |
| Pointer Color | Black |
| Pointer Material | Aluminum |
| Pressure And Vacuum Gauge Type | Pressure Gauge |
| Pressure Gauge Type | Process Pressure Gauge With Diaphragm Seal |
| Pressure Range | 0 psi to 30 psi |
| Pressure Range Type | Pressure |
| Primary Pressure Range | 0 psi to 30 psi |
| Primary Scale Minor Graduations | 1 |
| Primary Scale Numeric Increments | 10 |
| Primary Scale Units | Psi |
| Process Connection | 1/4" NPT Female |
| Process Connection Gender | Female |
| Process Connection Location | Bottom |
| Process Connection Size | 1/4" |
| Process Connection Type | NPT |
| Process Temperature Range | -4°F to +140°F |
| Range | 0 psi to 30 psi |
| Removable Bezel | Yes |
| Scale Type | Dual |
| Seal Compatible Process Media | Anything Compatible With PTFE And PVDF |
| Seal Diaphragm Material | PTFE |
| Seal Fill Liquid | Glycerin |
| Seal Lower Housing Material | Stainless Steel |
| Seal Lower Housing Material Grade | Grade 316 |
| Secondary Pressure Range | 0 psi to 60 psi |
| Secondary Scale Units | Bar |
| Sensor Material | Brass |
| Series | 701DDS-T-254 Series |
| Smallest Graduation | 0.5 psi |
| Socket Material | PTFE |
| Vibration Resistance | Field Fillable |
| Wetted Parts Material | PTFE, Brass |
Shipping Info:
| Ship weight (kg) | 0.36 |
| Ship height (cm) | 8.03 |
| Ship length (cm) | 13.59 |
| Ship width (cm) | 4.09 |
| HS code | 9026208000 |
| Country of Origin | CN |
Product Variants
| Product | Model | Graduations | Range | Accuracy | Price | |
|---|---|---|---|---|---|---|
 |
701DDS-252D | 10 psi | 0 psi to 60 psi | +/-2-1-2% | €38.57 |
