PARKER XV502P-16 Brass Ball Valve Inline Fnpt 1 In
Item: AB4ZDWModel: XV502P-16Cross Ref: 20K908
7 In Stock
Ships within 2 days via
5.00% off
€182.26 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Ball Valve |
| 3-a Certified | Not Rated |
| Ball Finish | Brass , Chrome Plated |
| Ball Port Style | Standard Port |
| Ball Valve Product Group | Manual |
| Body Material | Brass |
| Body Style | Inline |
| Coefficient Of Volume(cv) | 35 |
| Connection Gender Side 2 | Female |
| Connection Gender-side 1 | Female |
| Connection Size | 1" x 1" |
| Connection Size-side 1 | 1" |
| Connection Size-side 2 | 1" |
| Connection Type | FNPT x FNPT |
| Connection Type-side 1 | NPT |
| Connection Type-side 2 | NPT |
| For Media | Steam, Water |
| Handle | Lever |
| Handle Color | Yellow |
| Handle Length | 3.96" |
| Handle Material | Steel |
| Handle Type | Lever |
| Included Mounting | Base Pad |
| Max. Pressure | 600 psi WOG |
| Max. Pressure (cwp) | 600 psi |
| Max. Pressure-combustible Gas | Not Rated |
| Max. Pressure-steam | 150 psi |
| Max. Steam Pressure | 150 psi WSP |
| Media Temp. | 0°F to 350°F |
| No. Of Pieces | 2 |
| Nominal Valve Size | 1" |
| Overall Length | 2.75" |
| Pipe Size | 1" |
| Port | Standard |
| Pressure For Water | 600 psi WOG |
| Seal Material | PTFE |
| Seat Material | PTFE |
| Stem Material | Brass |
| Stem Type | Blowout Resistant |
| Temp. | 0°F to +350°F |
| Vacuum Service Rating | 29 in. hg |
| Valve Body Style | Straight |
| Valve Construction | Two-Piece |
| Valve Series | 502 Series |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 0.59 |
| Ship height (cm) | 10.92 |
| Ship length (cm) | 11.68 |
| Ship width (cm) | 10.67 |
| HS code | 8481801085 |
| Country of Origin | US |
Product Variants
| Product | Model | Ball Port Style | Nominal Valve Size | Port | Media Temp. | For Media | Connection Size-side 2 | Connection Size-side 1 | Connection Type-side 2 | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
XV500P-12 | Full Port | 3/4" | Standard | 0°F to 350°F | Air, Steam, Water | 3/4" | 3/4" | NPT | €52.07 | |
 |
XVP500P-4 | Full Port | 1/4" | Full | 0°F to 350°F | Air, Steam, Water | 1/4" | 1/4" | NPT | €18.28 | |
|
XVP500P-6 | Full Port | 3/8" | Full | 0°F to 350°F | Air, Steam, Water | 3/8" | 3/8" | NPT | €21.85 | |
|
XVP500P-8 | Full Port | 1/2" | Full | 0°F to 350°F | Air, Steam, Water | 1/2" | 1/2" | NPT | €24.20 | |
|
XVP500P-12 | Full Port | 3/4" | Standard | 0°F to 350°F | Air, Steam, Water | 3/4" | 3/4" | NPT | €37.81 | |
|
XVP500P-16 | Full Port | 1" | Standard | 0°F to 350°F | Air, Steam, Water | 1" | 1" | NPT | €89.46 | |
 |
XVV500P-4 | Full Port | 1/4" | Full | -40°F to +350°F | Air, Steam, Water | 1/4" | 1/4" | NPT | €25.12 |
