PARKER XV501P-4 Brass Ball Valve Fnpt x Mnpt 1/4 In
Item: AB4ZDLModel: XV501P-4Cross Ref: 20K898
7 In Stock
Ships within 2 days via
10.00% off
€12.38 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Ball Valve |
| 3-a Compliance | Not Rated |
| Ball Finish | Brass , Chrome Plated |
| Ball Port Style | Full Port |
| Ball Valve Product Group | Manual |
| Body Material | Brass |
| Body Style | Inline |
| Coefficient Of Volume | 8.23 |
| Connection Gender - Side 1 | Male |
| Connection Gender - Side 2 | Female |
| Connection Size - Side 1 | 1/4" |
| Connection Size - Side 2 | 1/4" |
| Connection Type | FNPT x MNPT |
| Connection Type - Side 1 | NPT |
| Connection Type - Side 2 | NPT |
| For Media | Air, Steam, Water |
| Handle | Lever |
| Handle Color | Blue |
| Handle Material Finish | Carbon Steel , Chrome Plated |
| Handle Type | Lever |
| Max. Pressure | 600 psi WOG |
| Max. Pressure (combustible Gas) | Not Rated |
| Max. Pressure (cwp) | 600 psi |
| Max. Pressure (steam) | 150 psi |
| Max. Steam Pressure | 150 psi WSP |
| Media Temperature Range | 0°F to 350°F |
| Nominal Valve Size | 1/4" |
| Number Of Pieces | 2 |
| Overall Length | 4.16" |
| Pipe Size | 1/4" |
| Port | Full |
| Pressure For Water | 600 psi WOG |
| Seal Material | PTFE |
| Seat Material | PTFE |
| Standards | Ansi B1.20.3 |
| Stem Material | Brass |
| Stem Type | Blowout Resistant |
| Temp. Range | 0°F to +350°F |
| Vacuum Service Rating | 29 in. hg |
| Valve Body Style | Straight |
| Valve Construction | Two-Piece |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 5.08 |
| Ship length (cm) | 10.41 |
| Ship width (cm) | 11.68 |
| HS code | 8481801085 |
| Country of Origin | US |
Product Variants
| Model | Overall Length | Pipe Size | Port | Ball Finish | Body Material | Connection Type | Max. Pressure | Max. Steam Pressure | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| XV501P-6 | 4.16" | 3/8" | Full | Chrome Plated | Brass | FNPT x MNPT | 600 psi WOG | 150 psi WSP | €18.06 | |
| XV501P-8 | 4.16" | 1/2" | Full | Chrome Plated | Brass | FNPT x MNPT | 600 psi WOG | 150 psi WSP | €26.05 | |
| XV501P-12 | 4.16" | 3/4" | Standard | Chrome Plated | Brass | FNPT x MNPT | 600 psi WOG | 150 psi WSP | €70.52 | |
| XV501P-16 | 3.54" | 1" | Standard | Chrome Plated | Brass | FNPT x MNPT | 600 psi WOG | 150 psi WSP | €68.00 |
