PARKER SST-3 Quick Coupling, 3/8 Inch Size, High Flow
Item: AC4XUYModel: SST-3Cross Ref: 31A968
7 In Stock
Ships within 2 days via
10.00% off
€147.72 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Quick Coupler |
| Application | Water And Coolant |
| Bearing Material | Stainless Steel |
| Bearings | Stainless |
| Body Material | Stainless Steel |
| Body Size | 3/8" |
| Configuration Type | Female NPTF |
| Connection Type | NPTF |
| Coupler Finish | Plain |
| Coupler/nipple/shell | Coupler |
| Coupling Component | Socket |
| Coupling Locking Type | Ball |
| Coupling Size | 3/8" |
| Finish | 303 Stainless Steel |
| Finish/coating | Plain |
| Fitting Type | FNPTF |
| For Use With | Parker St Series |
| Grade | Grade 303 |
| Hose Fitting Gender | Female |
| Hose Fitting Size | 3/8" |
| Includes Bearing | Yes |
| Includes Shut Off | No |
| Includes Valve | No |
| Interchange Type | Straight Thru Interface |
| Length | 1 16/25" |
| Lock Mechanism | Ball |
| Lock Type | Locking Balls |
| Material | Stainless Steel |
| Max. Flow Rate | 45.43 LPM |
| Max. Operating Pressure | 5500 psi |
| Max. Operating Temp. | 250 Deg F |
| Max. Operating Temp. | 250°F |
| Max. Outside Dia. | 1 5/32" |
| Max. Pressure | 5500 psi |
| Max. Pressure Range | Greater than 5000 psi |
| Max. Working Pressure | 5500 psi |
| Max. Working Pressure @ 70 F | 5500 psi |
| Min. Operating Temp. | -40°F |
| Operating Temp. Range | -40°F to +250°F |
| Overall Length | 1 41/64" |
| Parker Interchange | SST-3 |
| Pipe Size Npt | 3/8" |
| Quick Coupler Type | Water And High Flow |
| Seal Material | Nitrile |
| Series | ST Series |
| Sleeve Material | 303 SS |
| Sleeve Material | Stainless Steel |
| Sleeve Material Grade | Grade 303 |
| System Of Measurement | Inch |
| Temp. Range | -40°F to +250°F |
| Thread 1 Size | 3/8" |
| Thread Size | 3/8"-18 |
| Thread Type | Female |
| Type | Coupler (Body) |
| Valve Type | Unvalved |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 2.94 |
| Ship length (cm) | 4.17 |
| Ship width (cm) | 3.05 |
| HS code | 7307290090 |
| Country of Origin | US |
Product Variants
| Model | Coupling Component | Hose Fitting Gender | Hose Fitting Size | Coupling Locking Type | Thread Size | Body Size | Max. Working Pressure | Interchange Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| BST-1 | Socket | Female | 1/8" | Sleeve | 1/8"-27 | 1/8" | 2500 psi | ST | €25.55 | |
| BST-1M | Socket | Male | 1/8" | Sleeve | 1/8"-27 | 1/8" | 2500 psi | - | €27.25 | |
| BST-2 | Socket | Female | 1/4" | Sleeve | 1/4"-18 | 1/4" | 5200 psi | ST | €28.27 | |
| BST-2M | Socket | Male | 1/4" | Sleeve | 1/4"-18 | 1/4" | 5200 psi | - | €28.27 | |
| BST-3 | Socket | Female | 3/8" | Sleeve | 3/8"-18 | 3/8" | 2700 psi | ST | €37.25 | |
| BST-3M | Socket | Male | 3/8" | Sleeve | 3/8"-18 | 3/8" | 2700 psi | - | €37.25 | |
| BST-4 | Socket | Female | 1/2" | Sleeve | 1/2"-14 | 1/2" | 2200 psi | ST | €52.58 |
