PARKER SH2-63 Hydraulic Coupler Body, Stainless Steel, 3 gpm Flow Rate, 2000 psi
Item: AC4XQYModel: SH2-63Cross Ref: 31A898
7 In Stock
Ships within 2 days via
10.00% off
€63.63 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Hydraulic Coupler Body |
| Application | Hydraulic |
| Bearing Material | Stainless Steel |
| Bearing Type | Stainless |
| Body Material | Stainless Steel |
| Body Size | 1/4" |
| Configuration Type | Female NPTF |
| Connection Type | NPTF |
| Coupler Finish | Plain |
| Coupler/nipple/shell | Nipple |
| Coupling Component | Plug |
| Coupling Locking Type | Ball |
| Coupling Size | 1/4" |
| Finish | 303 Stainless Steel |
| Finish/coating | Plain |
| Fitting Type | FNPTF |
| Flow Rate | 3 GPM |
| For Use With | Iso 7241-1 Series B Coupler |
| Gender | Female |
| Grade | Grade 303 |
| Hansen Interchange | LL2-K16 |
| Hose Fitting Gender | Female |
| Includes | Heavy Duty Steel Nipples, Steam, Valve Actuator |
| Includes Bearing | Yes |
| Includes Shut Off | Yes |
| Includes Valve | Yes |
| Locking Mechanism | Ball |
| Locking Type | Ball |
| Material | Stainless Steel |
| Max. Flow Rate | 11 LPM |
| Max. Outside Dia. | 7/8" |
| Max. Pressure | 5000 psi |
| Max. Pressure Range | Greater than 5000 psi |
| Max. Working Pressure | 5000 psi |
| Max. Working Pressure @ 70 F | 5000 psi |
| Overall Length | 1 29/64" |
| Parker Interchange | SH2-63 |
| Pipe Size | 1/4" |
| Pipe Size Npt | 1/4" |
| Quick Coupler Type | Hydraulic General Purpose |
| Safeway Interchange | SS101-2 |
| Seal Material | Nitrile |
| Series | 60 Series |
| Shut Off | Double |
| Snap-tite Interchange | S72N4-4F |
| System Of Measurement | Inch |
| Temp. Range | -40°F to +250°F |
| Thread 1 Size | 1/4" |
| Thread Size | 1/4"-18 |
| Type | Coupler Male Half |
| Valve Design | Poppet |
| Valve Type | Poppet |
Shipping Info:
| Ship height (cm) | 2.22 |
| Ship length (cm) | 3.69 |
| Ship width (cm) | 2.29 |
| HS code | 8481803090 |
| Country of Origin | US |
Product Details:
- Parker Series 60 quick-connect coupling ideal for hydraulic applications involving frequent connection / disconnection of hoses
- Features hardened sleeves & nipples, in addition to captive valve seal for bubble-tight sealing
- Durable ball-locking mechanism ensures reliable connection each time
- Comes fitted with stainless steel locking balls and double O-rings for extra durability
- Unique seal design provides reliable sealing to withstand high pressure
Product Variants
| Model | Body Material | Coupling Size | Locking Type | Valve Type | Max. Pressure | Body Size | Material | Pipe Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| BH1-61 | Brass | 1/8" | Sleeve | Poppet | 1000 psi | 1/8" | Brass | 1/8" | €33.10 | |
| BH2-61 | Brass | 1/4" | Ball | Poppet | 1000 psi | 1/4" | Brass | 1/4" | €36.64 | |
| BH3-61 | Brass | 3/8" | Ball | Poppet | 1000 psi | 3/8" | Brass | 3/8" | €40.30 | |
| BH4-61 | Brass | 1/2" | Ball | Poppet | 1000 psi | 1/2" | Brass | 1/2" | €53.85 | |
| BH6-61 | Brass | 3/4" | Ball | Poppet | 1000 psi | 3/4" | Brass | 3/4" | €99.56 | |
| BH8-61 | Brass | 1" | Ball | Poppet | 1000 psi | 1" | Brass | 1" | €141.41 | |
| H1-63 | Steel | 1/8" | Ball | Poppet | 5000 psi | 1/8" | Steel | 1/8" | €24.65 |
