PARKER PBPP6VEU6 Ball Valve, 3/8 Inch Tube, 150 PSI CWP, 0-212 Deg F, Barb, Barb x Barb | CT7CUB 792RU8

PARKER PBPP6VEU6 Ball Valve, 3/8 Inch Tube, 150 PSI CWP, 0-212 Deg F, Barb, Barb x Barb

Item: CT7CUBModel: PBPP6VEU6Cross Ref: 792RU8
7 In Stock

Ships within 2 days via

€16.59
10.00% off
€14.93 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Ball Valve
Ansi Flange Class Not Applicable
Average Surface Roughness Not Applicable
Ball Material PSU
Ball Port Style Full Port
Body Material Polypropylene
Body Seal Material EPDM
Body Style Two Way
Compliance Meets 3A Sanitary Standards
Connection Gender - Side 1 Male
Connection Gender Side 2 Male
Connection Size - Side 1 3/8"
Connection Size - Side 2 3/8"
Connection Type Barb x Barb
Connection Type - Side 1 Barb
Connection Type - Side 2 Barb
Features Uniprene Washer
For Media Water
Handle Lever
Handle Color Gray
Handle Height 2 8/25"
Handle Material Acetal
Handle Type Lever
Hose I.d. 3/8"
Included Mounting Not Applicable
Manufacturer Warranty 1 yr.
Max. Pressure 150 psi
Max. Pressure (cwp) 125 psi
Max. Pressure (steam) 125 psi
Max. Pressure For Combustible Gas Not Rated
Media Temperature Range 0°F to 212°F
Nominal Valve Size 3/8"
Nsf Certifications For Food And Drinking Water NSF 51
Overall Length 2.13"
Pipe Schedule Compatibility Not Applicable
Port Full
Seal Material EPDM
Seat Material EPDM
Standards FDA
Stem Material PSU
Stem Type Blowout Resistant
Temp. Range 0°F to +212°F
Tube Size 3/8"
Vacuum Service Rating Not Rated
Valve Body Style Straight
Valve Construction One-Piece
Valve Structure One Piece
Vented Ball Valve Non Vented

Shipping Info:

Ship weight (kg) 0.02
Ship height (cm)2.54
Ship length (cm)5.41
Ship width (cm)2.54
Country of OriginUS

Product Variants

ProductModelBody MaterialConnection TypeMax. PressureSeat MaterialOverall LengthBall MaterialStem MaterialSeal MaterialPrice
PARKER 16A-SWB16L-RT-T-SS-LD-GR Ball Valve, 1 Inch Pipe, 1 Inch Tube, 2500 PSI, -65-350 Deg F, Compression, Comp. x Comp | CT7CQU 793G29 16A-SWB16L-RT-T-SS-LD-GRStainless SteelCompression x Compression2500 psiRPTFE5 9/25"Stainless SteelStainless SteelPTFE€2,126.29
PARKER HPBVB16FF Ball Valve, 1 Inch Pipe, 6000 PSI CWP, -65-450 Deg F, Female NPT, FNPT x FNPT | CT7CQV 803DY8 HPBVB16FFStainless SteelFNPT x FNPT6000 psiPEEK6.03"Grade 316316 Stainless SteelPTFE€3,501.78
PARKER FTPPB8VME8 Ball Valve, 1/2 Inch Pipe, 1/2 Inch Tube, 150 PSI CWP, 35-200 Deg F | CT7CQW 792RN7 FTPPB8VME8PolypropyleneTube x MNPTF150 psiBuna N2.34"PSUPSUBuna-N€25.06
PARKER LFPP8VME8 Ball Valve, 1/2 Inch Pipe, 1/2 Inch Tube, 150 PSI CWP, 35-200 Deg F, 1-Piece | CT7CQX 792RT4 LFPP8VME8PolypropyleneTube x MNPTF150 psiEPDM2.73"PSUPSUEPDM€28.02
PARKER 8A-SWB8L-RT-T-SS-LD-GR Ball Valve, 1/2 Inch Pipe, 1/2 Inch Tube, 2500 PSI, -65-350 Deg F, Compression | CT7CQY 793G27 8A-SWB8L-RT-T-SS-LD-GRStainless SteelCompression x Compression2500 psiRPTFE4.06"Stainless SteelStainless SteelPTFE€1,110.61
PARKER LFPP4VAS8 Ball Valve, 1/2 Inch Pipe, 1/4 Inch Tube, 150 PSI CWP, 35-200 Deg F | CT7CQZ 792RP6 LFPP4VAS8PolypropyleneTube x MNPTF x FNPTF150 psiEPDM1.79"PolysulfonePolysulfone-€26.99
PARKER LFPP4VMC8 Ball Valve, 1/2 Inch Pipe, 1/4 Inch Tube, 150 PSI CWP, 35-200 Deg F, 1-Piece | CT7CRA 792RP9 LFPP4VMC8PolypropyleneTube x MNPTF150 psiEPDM2.59"PSUPSUEPDM€28.55
