PARKER F200B Valve, 3 GPM Max. Flow, 2000 PSI Max. Pressure, Brass
Item: CT7FTXModel: F200BCross Ref: 1A853
7 In Stock
Ships within 2 days via
10.00% off
€106.87 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Valve |
| Actuation Mechanism | Manual |
| Adjustment Method | Rotary Knob |
| Body Material | Brass |
| Coefficient Of Volume (cv) | 0.23 |
| Configuration Type | Female to Female |
| Control Direction | One-Way |
| Cracking Pressure | 5 psi |
| Effective Control Flow Cv Factor | 5.25 |
| Effective Orifice Area - Control Flow (in2) | 0.23 sq. in. |
| Fluid Service | Oil |
| For Media | Oil |
| Free Flow Cv Factor | 23.9 |
| Free Flow Orifice Area (in2) | 1.046 sq. in. |
| Height | 1.54" |
| Includes Seals | Seals Included |
| Inlet Connection Gender | Female |
| Inlet Connection Size | 1/8" |
| Inlet Connection Type | NPT |
| Inlet Size | 1/8" |
| Length | 2" |
| Material | Steel |
| Material Poppet/stem Seals | Fluorocarbon |
| Max. Pressure | 2000 psi |
| Maximum Flow Rate | 3 GPM |
| Mounting | Inline |
| Operating Temp. Range | -40°F to +250°F |
| Operating Temperature - Maximum | 250°F |
| Operating Temperature - Minimum | -40°F |
| Outlet Connection Gender | Female |
| Outlet Connection Size | 1/8" |
| Outlet Connection Type | NPT |
| Outlet Port Type | NPT |
| Overall Height | 1.85" |
| Overall Length | 2" |
| Overall Width | 0.63" |
| Poppet Type | Soft |
| Port-to-port Length | 1 7/25" |
| Reverse Free Flow | Yes |
| Seal Material | Nitrile |
| Series | F Series |
| Thread 1 Size | 2" |
| Thread 1 Type | NPT |
| Valve Control | Flow Control |
| Valve Type | Flow Control Valve |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 1.6 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 3.91 |
| Country of Origin | US |
Product Variants
| Product | Model | Max. Pressure | Valve Type | Body Material | Max. Flow Rate | Inlet Connection | Outlet Connection | Reverse Free Flow | Seal Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
CV-1000-MFMF-5 | 3000 psi | Check | Steel | 100 GPM | - | - | Reverse Free Flow | Metal | €480.39 | |
 |
DC-1000-FOFO-5 | 3000 psi | Check | Steel | - | - | - | Reverse Free Flow | Metal | €279.39 | |
 |
CV-1000-MSMS-5 | 3000 psi | Check | Steel | - | - | - | Reverse Free Flow | Elastomeric, Metal | €477.74 | |
|
CV-370-MFMF-5 | 3000 psi | Check | Steel | - | - | - | Reverse Free Flow | Metal | €282.59 | |
 |
C800B | 2000 psi | Check Valve | Brass | - | - | - | Reverse Free Flow | Nitrile | €127.90 | |
|
C800S | 5000 psi | Check Valve | Steel | - | - | - | Reverse Free Flow | Nitrile | €132.52 | |
|
DC-1250-5 | 3000 psi | Check | Steel | 170 GPM | - | - | Reverse Free Flow | Metal | €455.00 |
